Home > Products > Series 3000 Aluminum Sheet/Coil > High Quality 3105 Aluminum Sheet from China
High Quality 3105 Aluminum Sheet from China
- 3000 Metric Ton / Metric Tons per Month
- Tianjin/Qingdao
- T/T
Product Details
Grade: | 3000 Series | Temper: | O-H112 | Type: | Coil |
Application: | Construction | Thickness: | 0.2mm-200mm | Width: | 100mm-1400mm |
Surface Treatment: | Other, Smooth | Alloy Or Not: | Is Alloy | Place of Origin: | Henan, China |
Brand Name: | Taihong | Model Number: | 3105 |
Product Description
3105 aluminum sheet/coil is 98% pure aluminum alloy with minor additions for strength. 0.3% of cooper is added to 3105 aluminum sheet/coil, so the conductivity turns out to be 41%. For its contents and processing technologies, 3105 aluminum sheet/coil is light in weight and it has semi-smooth surface. Besides, it is not hardened by heat treatment. All the products Of Mingtai Al. lives up to international standards, such as ASTM, EN, JIS, etc. Therefore, quality of 3105 aluminum sheet/coil can also be guaranteed. However, Mingtai Al. can supply particular specifications at customers’ need except the following.
Elements | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al | ||
Content | 0.6 | 0.7 | 0.3 | 0.3-0.8 | 0.2-0.8 | 0.2 | 0.4 | 0.1 | 0.15 | Remain | ||
Alloy | Specified thickness | Tensile | Yield | Elongation | ||||||||
(inches) | (KSI) | (KSI) | (%) | |||||||||
3105-O (annealed) | 0.013-0.019 | 96-145 | Min34 | 16 | ||||||||
0.020—0.031 | 18 | |||||||||||
0.032-0.080 | 20 | |||||||||||
3105-H12 | 0.017-0.019 | 131-179 | Min103 | 1 | ||||||||
0.020-0.031 | 1 | |||||||||||
0.032-0.050 | 2 | |||||||||||
0.051-0.080 | 3 | |||||||||||
3105-H14 | 0.013-0.019 | 152-200 | Min124 | 1 | ||||||||
0.020-0.031 | 1 | |||||||||||
0.032-0.050 | 2 | |||||||||||
0.051-0.080 | 2 | |||||||||||
3105-H16 | 0.013-0.031 | 172-221 | Min145 | 1 | ||||||||
0.032-0.050 | 2 | |||||||||||
0.051-0.080 | 2 | |||||||||||
3105-H18 | 0.013-0.031 | Min193 | Min165 | 1 | ||||||||
0.032-0.050 | 1 | |||||||||||
0.051-0.080 | 2 | |||||||||||
3105-H25 | 0.013-0.019 | Min15 | Min131 | 2 | ||||||||
0.020-0.031 | 3 | |||||||||||
0.032-0.050 | 4 | |||||||||||
0.051-0.080 | 6 |
Mg, Mn and Si are added to 3105 aluminum sheet, thus, it has excellent correction resistance, formability and welding characteristics. Besides, it has average mechinability and it can be increased in harder tempers than in annealed condition. Oil lubricants should be used for all machining operations. The forming characteristics of 3105 aluminum sheet/coil are pretty good by all conventional processes regardless of temper. But 3105 aluminum sheet/coil does not respond to heat treatment except for annealing during cold working. The cold working characteristics are very good, even in the harder cold working tempers. For all the features above, 3105 aluminum sheet/coil has a vast application in many field.
Building Application
Ceiling
Residential Siding
Mobile Homes
Rain Carrying Goods
Truck/Trailer Roofing
Sheet Metal Work
Sign Making
Traffic Sign
Presently, the company’s products cover aluminum alloy products of Series 1xxx, Series 3xxx, Series 4xxx, Series 5xxx, Series 6xxx, Series 7xxx, Series 8xxx of different sizes. Main products include CTP plate stock, PS plate stock, aluminum electrode capacitor foil, foil stock, deep-draw stock, brazing sheet, alloy sheet and plate, etc. Those products are widely applied in industries including automobile making, traffic and transportation, packaging and containers, buildings and decorations, electrical and electronic, printing, etc.
Production capacity: 650, 000 tons annually.
Technologies: Advanced equipments and 18 years experience.
Employees: Over 2, 800 experienced employees.
Markets: Obtain market sharing all over the world.
Packaging: Cover film, brown paper or wooden pallet at customers’ need.
Responsibility: Engaged in charity donation and provide eco-friendly products.
1) Plastic film and brown paper can be covered at customers' need.
2) Wooden case or wooden pallet is adopted to protect products from damage during the delivery, especially from seawater.
3) There are two kinds of packaging, which are eye to wall and eye to sky.
4) There are 2 tons in one package, and loading 18-22 tons in 20 feet container, and 20-24 tons in 40 feet container.
Q1: When can I get your reply after the inquiry?
A1: Within 12 hours, our professional sales rep will contact you to offer a quote.
Q2: What if I want to know more details about your company and products?
A2: Please kindly refer to our offcial website at for more information.
Q3: Can I pay a visit to your factory to evaluate your comprehensive strength?
A3: Of course you can. We would be appreciated to have your coming to China.
