Help CenterBLACK Dual Link DVI 24+1 Male to Dvi 24+1 Male Cable Conncetor
Related Products
-
1080P 28AWG DVI 24+5 Male to Male Cable With Low PriceUS$ 0.5 - 1.6MOQ: 1000 Pieces -
1080P 6 ft DVI 24+1 to HDB 15 Pin Male to Male Cable With Low PriceUS$ 0.5 - 1.5MOQ: 1000 Pieces
-
1080P DVI 24+1 Male to Male With Low Price Factory SupplyUS$ 0.5 - 1.6MOQ: 1000 Pieces
-
28AWG 6FT DVI 24+1 to HDB 15pin Male to Male CableUS$ 0.6 - 3.2MOQ: 1000 Pieces
-
28AWG 5ft DVI 24+1 to HDB15pin + DVI 24+5 Female Cable High QualityUS$ 0.3 - 3MOQ: 1000 Pieces
Specifications
1.Dual Link DVI 24+1 male to dvi 24+1 male cable conncetor2.UL standard ROHS compliant
3.28#copper conductor
4.gold plated
Product name:
Dual Link DVI 24+1 male to dvi 24+1 male cable conncetor
Technical Details
SPECIFICATIONS | |
Conductors |
High purity Tinned copper |
Insulation |
Foamed PE|Skin(Chemical Foam) |
Contacts |
24K Gold Plated |
Connectors |
Metal shell type (optional) |
Available lengths |
3FT to 50FT ( 1m,1.8m,3m,5m,10m,15m ) optional |
Available terminations |
dvi 24+1 dual link |
Available gauge |
26/28AWG (optional) OD:6.2/7.3mm |
Certification |
RoHS, UL,CE |
Shielding |
AL+ ML+ Braiding+ Ferrite Coverage:45%.65%.85%) Inner Shielded:AL-Mylar 100%(min)coverage |
jack |
pvc |
Typical Applications:
• Splitting a DVI-I signal to DVI-D
• Connecting a single DVI-D dual-link device to a DVI-I dual-link device and a VGA device.
Features:
1. DVI-D Male to Male Digital / Digital Single Link Cable
2. Digital Visual Interface (DVI) is the standard interface for a high-performance connection between PCS and flat panel displays, digital CRT displays, projectors, an HDTV.
3. DVI Single-Link Digital/Digital Video Cables from Impact Acoustics deliver the high-performance, high-bandwidth interface needed for video displays of today while leaving headroom for the products of tomorrow.
4. These precision-engineered cables are fully compliant with the DVI standard defined by DDWG (Digital Display Working Group).
5. The DVD-D configuration provides enough bandwidth for resolutions up to 2048 x 1536 and allows high speed digital transmission up to 9.9 Gbps.
6. Connectors: DVI-D (18+1 pin) , DVI-D (18+5pin),DVI-D (24+1 pin) , DVI-D (24+5pin)
7. The digital signaling allows for high speed transmission up to 9.9 Gbps
8. Shielded undermold protects against unwanted EMI/RFI interference
9. Double-shielded with Mylar foil and braid shield reduces interference
10. Gold-plated contacts provide full conductivity without ghosting and data loss
11. Supports hot plugging of DVI display devices
12. Resolutions up to 2048 x 1536
13. Supports digital signal only
14. With thumbscrews for easy installat
