Help CenterVery Cheap Price ZYS400B-B Hydraulic Static Press Pile Driver With High Quality
Related Products
-
Best Sell ZYS400B-B Hydraulic Pressure Static Pile Driver With High Quality in South-east Asia CountriesUS$ 198,000 - 244,600MOQ: 1 Set -
New Condition ZYS 240 Ton Hydraulic Static Press Pile Driver for SaleUS$ 125,800 - 152,400MOQ: 1 Set
-
Juli Brand ZYS400B-B Hydraulic Static Pile Driver for SaleUS$ 198,000 - 244,600MOQ: 1 Set
-
Find China 420 Ton Hydraulic Piling Equipment, ZYS420 B-B Hydraulic Static Press Pile Driver for VietnamUS$ 150,000 - 250,000MOQ: 1 Set
-
ZYS Series 420 Ton Hydraulic Slient Press Pile Driver With Best PriceUS$ 150,000 - 250,000MOQ: 1 Set
Juli brand ZYS static hydraulic pile driver which is researched and produced independently is one of the Chinese characteristic large model green pile machine for foundation construction. The construction of precast pile entirely depends on the pressure of the hydraulic static pile. It has the characters such as, no vibration, no noise, high efficiency, energy-saving, high piling rate, excellent quality pile. It has been widely used in the engineering construction and also got the great reputation in the field of civil engineering machinery and equipment.
Main Type: ZYS60, ZYS80, ZYS120, ZYS240, ZYS320, ZYS400, ZYS500, ZYS600, ZYS700, ZYS800, ZYS900, ZYS1000, ZYS1200
| Dongtai Juli Machinery Manufacturing Co., Ltd | |||
| Type | ZYS400B-B | ||
| Rated piling pressure | tf | 400 | |
| Piling speed | High | m/min | 6.5 |
| Low | 1.2 | ||
| Pace | Longitudinal | m | 3.6 |
| Horizontal | 0.6 | ||
| Angle range | ° | 11 | |
| Rise stole | m | 1 | |
| Square pile | Min. | mm | 400 |
| Max. | 500 | ||
| Circle pile | Min. | mm | Ø300 |
| Max. | Ø400 | ||
| Side piling space | mm | 1380 | |
| Corner piling space | mm | 2800 | |
| Lift weight | t | 12 | |
| Lift pile length | m | 14 | |
| Power | Piling | kW | 111 |
| Lifting | 30 | ||
| Dimension | Working length | m | 13 |
| Working width | 7 | ||
| Transportation height | 3.5 | ||
| Gross weight | t | 400 | |
1. Crane
2. Vertical motion mechanism
3. Piling platform
4. Pile clamping box
5. Main cabin
6. Side piling installation set
7. Assistant cantilever
8. Cross motion and rotary mechanism / Short base
9. Longitudinal motionmechanism / Long base
Dongtai JuLi Machinery Manufacturing Limited Company, located in the beautiful coast of the yellow sea, Dongtai,No.9,BeiGuan road ,Economic development zone, Jiangsu province.Our factory covers an area of 80 acres, plant area of 30000 square meters, with vehicles, drilling, planing, milling, grinding and other kinds of various machine more than one hundred sets, equipped with 32 tons and16 tons gantry crane, and dozens of forklifts .
The company has many years of experience in machinery manufacturing and sophisticated equipment, is specialized in designing and manufacturing large engineering machinery, horizontal directional driller and supporting tools.because of our reliable quality, perfect service, products are sold well in China and exported to over ten abroad countries , deeply welcomed by the clients.
- Provide technical training for customers
- Timely troubleshoot problems on site
- Supply spare parts in time
- Periodically revisit customers and know their needs
1) How can I place order?
A: You can contact us by email about your order details, or place order on line.
2) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank) and Paypal, Western Union are the most usual ways we are using.
3) What’s the order procedure?
A: First we discuss order details, production details by email or TM. Then we issue you an PI for your confirmation. You will be requested to do pr -epaid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-15days if we don’t have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
4)How do you take care when your clients received defective products?
A: replacement. If there are some defective items, we usually credit to our customer or replace in next shipment.
5)How do you check all the goods in the production line?
A: We have spot inspection and finished product inspection. We check the goods when they go into next step production procedure. 1) How can I place order?
A: You can contact us by email about your order details, or place order on line.
2) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank) and Paypal, Western Union are the most usual ways we are using.
3) What’s the order procedure?
A: First we discuss order details, production details by email or TM. Then we issue you an PI for your confirmation. You will be requested to do pr -epaid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-15days if we don’t have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
4)How do you take care when your clients received defective products?
A: replacement. If there are some defective items, we usually credit to our customer or replace in next shipment.
5)How do you check all the goods in the production line?
A: We have spot inspection and finished product inspection. We check the goods when they go into next step production procedure.
