Ptfe Thin Flat Gasket

Name: Ptfe Thin Flat Gasket
Brand: NXptfe
SKU: 117608699
Availability: InStock

US$ 1 - 20 MOQ: 200 Kilograms

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

NXptfe

Model Number:

Ptfe shims washer

Huzhou Ningxin New Material Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai / ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name NXptfe

Model Number Ptfe shims washer

Material Other, ptfe

Shape Ring Gasket

Standard or Nonstandard Other, other

Specifications

ptfe washers
1.excellent chemical properties
2.acid and alkali resistant
3.wide working temperature range
4.low friction

ptfe washer

Compared with other plastics, ptfe washer has better corrosion-resistance and excellent heat-resistance.

It is now widely used as sealing material.

Usage
They are usually used as corrosion-resistance under -180 - 200°C, and sealing parts in ordinary electric property conditions.

Main technical indicator
1) Apparent density: 2.10 ~ 2.30g/cm³
2) Tensile strength: ≥15.0Mpa
3) Ultimate elongation: ≥150%

available sealing gasket standard

Inner diameter×outer diameter×thickness	Approximate weight(g)	Inner diameterouter diameterthickness	Approximate weight(g)
20×6×3	2.2	65×32×3	16.7
22×6×3	2.3	66×40×4	13
24×6×3	2.8	75×65×4	10
27×6×3	3.5	78×45×3	22
28×8×3	3.4	80×40×5	41.5
28×6×3	4.5	85×49×3	25
32×10×3	5	90×15×5	159
34×8×3	6.4	90×60×5	40
40×12×3	7.6	93×85×3	7.5
40×25×3	5	96×50×5	59
42×10×3	8.6	96×44×4	55
42×12×4	12.6	100×50×5	65
50×20×4	14.5	100×57×3	35
50×32×3	7.8	120×60×5	97.4
52×20×4	16	120×63×5	92
55×25×3	12.4	145×81×5	125.5
57×27×3	13	172×96×5	138.5
60×30×4	18.7	228×212×20	247
62×37×3	12.8	280×260×20	390
64×30×4	22.1
