ENG Power Factory Direct Sale 250kva Diesel Generator With Cummins Engine

Genset specification

Genset Model

ENSC250S-3

Prime Power(50HZ)

200KW /250KVA

Standby Power(50HZ)

220KW /275KVA

Frequency/Speed

50Hz/1500rpm

Standard Voltage

230V/400V

Voltage Available

220V/380V,240V/415V

Phases

Three phases, four wires

Engine Specification General Performance

Manufacturer:

Dongfeng Cummins Engine Company Ltd.

Engine Model:

6LTAA8.9-G2

Engine Type:

4-Cycle; In line; 6-Cylinder Diesel

Engine Speed:

1500 r.p.m

Prime Power:

220kw /295BHP

Standby Power:

240kw /322BHP

Governor Type:

Electrical

Air Intake Way:

Turbocharged and charged air cooled

Displacement:

8.9L

Cylinder Bore * Stroke:

114mm × 145mm

Compression Ratio:

16.6:1

Coolant Capacity Engine Only

11.1 Liters

Alternator data

Engine Model:

Stamford    UCDI274K

Phase

3 Phase

Power Factor

0.8

Drip Proof

IP 23

Insulation class

H

Voltage regulation

± 0,5 %

Altitude

≤ 1000 m

Over speed

2250 min -1

Genset Standard Configuration

♦ Assembled by Cummins diesel engine and world famous brand alternator
♦ Radiator and fan with safety guard
♦ Automatic control panel and electricity output switch cabinet
♦ Float battery charger and solenoid switch as standard supply scope
♦ Built-in shock pad
♦ Heavy duty steel as base frame and 6-8hrs operation base fuel tank.(suit for 8kva-750kva)
♦ Optional voltage rank: 230V/400V, 220V/380V, 127V/220V, 240V/480V etc.

Engine Manual and Catalogue

Our Project reference

More choose:

Powered by Cummins series power range from 20kva-1500kva.

Welcome inquiry to us, EN Power sales team will send our proposal to your immediately.
