carton packaging industrial stapler/nailing machine
| Model | Unit | DX-1200 | DX-1400 | DX-1600 | DX-1800 |
| Max paper size | mm | 1200 | 1400 | 1600 | 1800 |
| Speed | stitch/min | 300 | 300 | 300 | 300 |
| Stitching thickness | mm | 5~9 | 5~9 | 5~9 | 5~9 |
| Min. stitching pitch | mm | 18 | 18 | 18 | 18 |
| Stitching type | 450 double nail | 450 double nail | 450 double nail | 450 double nail | |
| Operation height | mm | 1200 | 1200 | 1200 | 1200 |
| Power | kw | 0.37 | 0.37 | 0.37 | 0.37 |
| Weight | kg | 350 | 400 | 450 | 500 |
| Overall dimension(L*W*H) | mm | 1500*600*1900 | 1700*600*1900 | 1900*600*1900 | 2100*600*1900 |
This machine is elaborately designed combined with the advantages of the same products both at home and aboard, featuring novel appearance, brisk movement, stable running, firm stapling and long service life.
This machine is adapt to small quantity box production, it can produce several thousands pcs every day and it is mainly by manual, it is stapling tide and tough, It is the best choice for small business and also for middle size business, it is cheap and not take big area, when you have carton boxes to stapling,you can use it stapling, when there is no orders, you can put it there, just several thousand RMB,cheap and convenient.
1. manual carton stitching machine
2. nails in the form of: single, double.
3. Installation: Place the cement floor in general.
4. stapling machine,stitching machine,box press machine.
5. Maintenance: oil 2 times each day.
6. The angle of nail: 45 degrees angle.
7.stitch stapler industrial stapler machine .
Dongguang Country Hongsheng Carton Machinery Factory is a well known enterprise engaged in the professional production of various kinds of carton machines. Our products are complete in specificati-
on and model, and can meet the needs of different users. Our main products are corrugated board p-
roduction lines, ordinary printing presses, high speed printing presses, single facers, thin blade mac-
hines, and rotary die cutting machines, In the spirit of "excellence and continuous pursuit of perfectio-
n", on the basis of"ensuring quality and service", we pay more attention to corporate reputation and
always adhere to the "reputation first" principle.
1. Packing type:carton or wooden case , also be packaged according to customer requirements.
2. Modes of transportation:by sea ,by air or land transportation, Of course, a small amount can also by Express.
If you are interested in our products, please feel free to contact us.
Welcome to vist our factory at any time!
Add:Hebei province Dongguang development zone
Fax:0317-7669161
Tel:0317-7669167
QQ:1606466954
MP:13582724787
