Specifications
Veneer stitching jointing machine1.easy operation
2.saving meterail and labor
3.for short veneer
4.with glue thread
1400mm plywood veneer stitching machine/veneer jointing machine
Technical specifications
Suture Max. width: |
1300mm |
Suture Max. length: |
infinite |
Suture thickness: |
0.4-3mm |
Feeding speed: |
0-50m/min |
Working table high: |
900mm |
Chief motor: |
0.75kw, 380V-50Hz 3phase |
Hot-wind power: |
0.5kw, 380v-50Hz, 3phase |
Overall dimension: |
2230x700x1600mm |
Plywood package size: |
2310x780x1630mm |
Weight: |
600kgs |
The advantages of this veneer stitching jointing machine
PF1300 veneer splicer is the ideal equipment of connecting veneer, even use the veneer with
different thickness, the feed plate with tolerance compensation can absolutely ensure evenly
bond surface. Bonding line can automatically smear by ‘Z’ subtype to ensure the bonding
and sealing be solid. Even use curving veneer, can also effectively prevent wear and
disconnect.
Product showing
Packing and shipping: Usually the plywood veneer stitching jointing machine packed in nude. One 20 container just for 5 sets. Or plywood packing for LCL
The port is QINGDAO or LIANYUNGANG. And if necessary, we will provide the ship according the arraived port for you.
If the veneer stitching jointing machine matched with the whole plywood producing line:
1.We will send our engineer under your indications to your factory for installing, debugging and maintaining, you only need to afford the cost of the flights, and the engineer's accommodation .
4.After the warranty, we can also supply the engineer service and the technical service, but you need to pay the salary for the engineer! and afford the cost of the replaced aparts yourself.
If the veneer jointing machine is separate, we will provide the operation manule, no need the oversea service.
We are the leading manufacturer in woodworking industry in Linyi City, China. Our main products are plywood line and particle board line, and there are also factories for plywood, particle board and MDF producing.
Customers cover most of the world, from Vietnam, Indonesia, India, Iran, Dubai, Nigeria, Algeria, South Africa, Garner, Brazil, American and Russia.
Any question from you will be appecaited, and well come to Linyi China for visit!
