Automatic veneer line with debarker, peeler, cutter, stacker
Log Debarker is used forlog for round before peeling. And it is suitable for the eucalyptus, pine, with principle
of peeling, removing the log’s skin and straighten logs. Hydraulic driven feed mechanism,can quickly, efficiently put log removal of bark, round. One set debarker can supply 2 set peeling machine .it saves the original manual
peeling, rounding procedure, save 5-6 workers.
Main features:
1.Increase of single and double roll’s diameter, improving the speed of remove skin .
2.Single, double roll surface with chrome plating, improve wear resisting of roller.
3.The hydraulic feeding mechanism, a cutter, rapid, and feed pressure can be adjusted and display, adapt to
different wood .
4.Simple operation, convenient maintenance, requirements for operators and workers is not high technology.
Our engineers have improved the debarker technology
1.Our CNC log debarking and rounding machine is very usefull and efficient to rotarily cut off the majority bark from the pine branch material or wood and make them straightly and smoothly.
2.The debarker machine has two fixed roller and the knife block moves with the power of two hydraulic hands.
Type |
8ft Log Debarker |
4ft Log Debarker |
Length of peeler log |
2700mm |
1400mm |
Diameter of peeler log |
700mm |
700mm |
Speed |
55m/min |
55m/min |
Size of the blade |
2700x180x16mm |
1500x140x12.7mm |
|
Total Power |
Double roller motor 11 kw |
Double roller motor 7.5 kw |
Single roller motor 11 kw |
Single roller motor 7.5 kw |
|
Hydraulic roller motor 4 kw |
Hydraulic roller motor 4 kw |
|
Overall size |
4900x2200x1450mm |
3560x2150x1100mm |
Weight |
About 4800KG |
About 2500KG |
1. This log debarking machine is the basic plywood machine,
it is used to debark and round the logs before peeling, after rounding ,
the logs will become straight and smooth, and easy to peel by veneer peeling machine ,
2. It is hydraulic working system, which is easy to operate,
not easily broken down, easy to repaire .
3. The hydraulic system is equipped with cooling system,
4. It has three rollers , and can round a log in only 5s ,
5. It is designed for hardwood, such as eucalyptus, rubber wood, mango wood, etc .
6. It is now very popular in South China, and in Vietnam, Thailand, India, Indonesia etc .
7. Both 4ft & 8ft machines are available .
We will stay in line for above 14 hours, so any questions about the products we can reply in detail, when off line, please send us emails, we will reply ASAP.
