Specifications
1.Size:58*30*23mm2.Input:AC/DC12V
3.Output:1-4*1w,3-15V,310mA
4.CE approval
5.led driver
Any other requirements,please do let me know, because there are other kinds of LED Driver in our company. In addition, we can design the product according to your requirement.
1-4*1w 3-15V 310mA constant current led driver
Product Information
| Output Voltage | 3-15V |
| Output Current | 310mA±5% |
| Output Watt | 1-4*1W |
| Output Voltage | 2-24V |
| Output Current | 310mA±5% |
| Output Watt | 1-7*1W |
| Type | Constant Current |
| Input Voltage | AC/DC12V, AC/DC24V |
| Output Ripple | 2Vp-p |
| Size | 58*30*23mm |
| Efficiency | 85% |
| Frequency | 47-63Hz |
| PF | ≤0.65 |
| Temperature | -25°C~+65°C |
| Modulation | PWM |
| Insulation | Yes |
| MOQ | 1 pcs |
| Warranty | 2 Years |
Product Picture
Certificate
Quality Guarantee
1.The warranty period is 2 years.
2. If the products have any question during the time, we can fix it or change the same to you.
3.We can design the product according to your requirement. If you want to guarantee over 3 years, the price could be negotiated separately.
Storage
1. Keep Dry, don’t shock
2. Storage in below 35°C, humidity less than 75% environment
Tips
1. The product must be connected the LED lamps, and, can't no-load power for a long time then turning on the product
2. Do not short circuit.
3. Please refer to the instruction manual before use.
4. If not sure how to use the product, please contact us before use.
Protection
Short circuit / over current / over voltage/ Over load/ Over temperature
Payment
Packing
Shipping
Our service
1.OEM order is available, could also print your company logo or specific label.
2.Samples could supply to you.
3.Professional sale services. Any questions, could contact us any time.We will reply you within 24 hours.
Production Process
About Us
SOLUXLED Lighting Electron Factory is a high-tech enterprise of jiangmen city guangdong china. Our company and our products have confirmed by Bureau Veritas ( BV Certification ) .
We manufacture sell communication LED driver with constant current power supply, DC power supply, UPS power supply, Waterproof led driver, internal led driver, external led driver, RGB led driver, RGB controller, DMX512...etc LED related products. With full integration of design, research, development, production and sales.
