Remote Control Roll up Door

Specifications

The specification of remote control roll up door

Product Uses:

IJM-2800 type internal channel high speed door, specially design for the narrow space logistics channel, the built-in type motor doesn't take up installation space, meet the special places need. The curtain consists of the lighter door curtain fabric and aluminum wind rib, improve speed, safe and reliable, come in and go our conveniently, anti-insect, dustproof.

Application Environment:

>>>access door

>>>light industry,food industry,electron,storage,package,print,chemical industry

>>>high frequency switch environment

IJM-2800  type internal channel high speed door

Appearance: high strength antioxidant aluminum alloy frame 120*130mm, silvery white,accord with 6063-T6 standards, cold steeling rolling plate, spraying door 140*1450mm, cold steeling rolling plate electrostatic spraying door head cover.

Motor: Germany SEW motor, power 0.75-1.5kw, power 220v, brake voltage 220v.

Controlled System: Import microcomputer frequency conversion control electric box( Mitsubishi CPU)

Controlled Voltage: safety low voltage24 VDC

Speed: open 0.8-1.5m/s; close 0.6-1.2m/s ( speed can be adjusted)

Curtain Material: Imported high-density polyester surface coating processing thickness 0.8-1.5mm, many colors for choosing.

Tensile Strength: 5700/5100N/5cm; Fearing strength 900/80N

Fire protection: German standard MZD/NBL fireretardant

Using Temperature: -10°C---+70°C/ super cold area -40°C

Transparent window: Imported PVC transparent crystal soft board, thickness 1.5mm, oblong or elliptic.

Wind-resistant Material: aluminum alloy wind-resistant rib, section connection and easy to change.

Wind-resistant Power: 9m/s (50Pa standard 3*3)

Sealing Performance: door curatin bottom U type aerocyst cloth pouth can totally close to the uneven plane.

Security Configuration: standard infrared photoelectricity protection, air-bag pressure, warning lights, bull column, power manual rocker.
