Large diameter tube drawing bench/drawbench for drilling work
Application
DF~YB~80 tube drawing bench are different kinds of engineering and Drilling drill auxiliary equipment for pile construction,jet grouting drilling technology, and other anchor hole drilling projects. It is used for pulling for casing pipe and drill pipe, can also be used to deal with accidents to pull drill casing and drill pipe out of well.
Structural features
The series consists of pump stations, extubation cylinder, base and other component parts. When slip grip casing or drill pipe, the reciprocating cylinder to pull from the casing and drill pipe. This series is closed integrated structure, small size, safe and reliable, stable operation and so on.
The machine uses a hydraulic servo~balanced organization, pull smoothly, Cylinder force uniform. users can also use longer tubing with different working site. Pulling casing in larger area, reducing the times of moving.
This pulling machines light weight, strong pull force, good dismount~ability, easy handling migration, especially for the slope, trenches, mountains and other construction sites. Can place a variety of slip seat into the slip seat cone as per customer different requirement, to grip different specifications casing.
Specification
Puller | |
Rated pulling force |
1200KN |
Stroke |
550mm |
Max.pulling diameter |
325mm |
Commutation way |
manual commutation |
Speed Adjustment |
Pulling the direction of one-way flow control |
Hydraulic station | |
Structure |
Trailer type |
Normal system pressure |
31.5 Mpa |
Pump displacement |
60ml/r |
Power supply |
Diesel engine 24kw |
Starting method |
Electric start,24v |
Transmission |
Direct coupling |
Tube drawing bench On-site photos
