424999 424926 Used Auto Parts Germany Disk Brake Used for Citroen Jumper Bus

Name: 424999 424926 Used Auto Parts Germany Disk Brake Used for Citroen Jumper Bus
Brand: Winmann
SKU: 117531917

US$ 4 - 10 MOQ: 50 Pieces

Key Specifications

Type:

Brake Discs

Material:

Gray Cast Iron

Certification:

ISO/TS 16949

Shanghai Winsun Auto Parts Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Type Brake Discs

Material Gray Cast Iron

Certification ISO/TS 16949

Size Standard

Car Make Other

OE NO. 4249H8 4249K3 424999 424926 424927 4246L4 4246Y1 4246L2 4246X9

Place of Origin Shanghai, China

Brand Name Winmann

Model Number 424999

424999 424926 Used Auto Parts Germany Disk Brake Used for Citroen Jumper Bus

Reference Number
4249H8 4249K3 424999 424926 424927 4246L4 4246Y1 4246L2 4246X9 1607872080 51848619 46806233 1300501080 51740244
Vehicle Application
Passenger Car
Specification
	Item Name	424999 424926 Used Auto Parts Germany Disk Brake Used for Citroen Jumper Bus
A	Diameter	280 mm
B	Brake Disc Thickness	24 mm
C	Centering Diameter	73 mm
D	Height	67.6 mm
E	Pitch Circle Diameter	118 mm
	Number of holes	5
	Location	FRONT
	Solid or Vented	VENTED

6.1 Material Paragram of brake disc, rotor & brake drum:

Standard	C	Si	Mn	P	S	C.E
G3000	3.1~3.4	1.9~2.3	0.6~0.9	≤ 0.15	≤ 0.15	3.90~4.15

6.2 Mechanical Properties of brake disc, rotor & brake drum:

1) Tensile: ≥ 210 Mpa
2) Hardness : 160~241 HBS

6.3 Microstructure of brake disc, rotor & brake drum:

Main Graphite Type: A , Grade: 3~5 .
Pearlite: ≥95% Ferrite: <5%

Main Products
*C.V. Brake Disc/C.V. Brake Drum/C.V. Brake Pad Set/C.V. Brake Shoe Set/C.V.Brake Lining/Flywheel*
*Auto Brake Disc/Auto. Brake Drum/Auto. Brake Pad Set*
Main Application
*European & American & Japanese Commercial Vehicle, Main Brand Passenger Car*
