miner's lamp LED mining lamp LED miner lamp miner's lamp led lamp headlamp led mining safety lamp)Miner's lamp Main technical parameters:
| No | Item | Unit | Data | |
| 1 | Rated capacity | Ah | 2.8 | |
| 2 | Nominal voltage | V | 3.6 | |
| 3 | Lighting time | h | 15 | |
| 4 | LEDlight source | Power | W | 1 |
| Main light source | mA | 200 | ||
| Auxiliary light source | mA | 110 | ||
| 5 | Max illuminance at 1m | Begin lighting | Lx | 3500 |
| Lighting 11h | Lx | 3000 | ||
| 6 | Weight | g | 130 | |
| 7 | Nos of battery cycle | times | 800 | |
| 8 | Carton packing | pcs/CNT | 60 | |
| 9 | Packing size | cm | 36x40x53 | |
| 10 | With charger | pcs | 1 | |
Usage:
It is suitable for mineral industry,tunnel projects,construction and maintenance for power,
communication,highway,railway at night,night lamp for cutting off rubber plant and absorbing mucus and for lighting a flood,rescuing and marine use.
Features:
Lost cost ,high safety.
1. LED : less energy and super brightness LED
2. Battery : safety lithium ion battery
3. Small in size, light in weight, free maintenance, explosion prevention, waterproof, long life
4. Lighting time : more than 13 working hours, double light source design
5. Charger AC input : AC110 ~ 240V, 50/60Hz DC output : DC4.2V,1A
6. Working temperature : -10 ~ 45 degrees
7. Relative air humidity : <= 95% +- 3RH
It adpot new styled lithium ion battery which is with over-charging , over-discharging and a short circuit protection fuction.Every battery cycled lifetime is more than 500 times.It has 75% rated capacity after using 500 times.Its a newest environmental protection battery.
2. LED:it adpot 1W high-power Led,The life is more than 50000 hours.illumiance is more than 1200 lux/30lm,it adpot two sets of light source,one is main - six auxiliary light source or main-axiliary in one .when main light source lose function,pls turn a switch axis into auxiliary light source then it go into work normally(This is for meet an emergency)
3. Charger(Lithium ion):
It adpot isopiestic pressure current limiting charging way.Its setting value volatge is 4.2V(normal charging voltage is 4.2V).
When charging max current is 1A and voltage approachs to 4.2V,charging current will reduce gently.When batterys voltage is 4.2V and current is less than 100A,the indicator light will display green color.this mean that miners lamp can be used normally.When its charging ,the indicator light will display red color.
Product images:

Package Details:
60pcs to a box
Delivery Details:
Port: Shanghai, Ningbo
Lead Time: 7-10 working days after received deposit.
Transportation: DHL/ UPS /Fedex /EMS/ TNT (door to door ) or by ship /by air or use customer forwarder.
The above products can be find in the store
address: http://bozz.en.china.cn/productgrouplist-801314601/Hot_Product_Recommended_Products.html
♣ Samples
Samples are avaliable for Testing and Market Test.
♣ Warranty of Products
Wenzhou Boshi provides warranty against defects in materials and workmanship, We strictly control every production process, the product provides 6 tests before leaving factory.
♣ Guides and After-service Consultancy
Wenzhou Boshi Team will offer these guides below
A .Need an Accessory?
B.Products Repair?
C.How to solve some quality problem?
Hours After-service consultancy just for you and to make your problems to solve easily.
♣ OEM service
OEM service of Wenzhou boshi is strictly based on the ISO9001 ISO14001 quality assurance system.The TOP involves the effective teamwork of departments from Sales, R&D, and Engineering, Purchasing,production&QA, assuring a high quality product and prompt delivery for customers. The standardization of our quality system and the quality stability has earned us the trust of our customers for 9 years.
![]() | Founded in 2006.wenzhou Boshi Electric Technology Co.,Ltd is a professional manufacturer specializing in mining lamp, mining electrical apparatus,move lighting fixture,explosion-proof and lighting products.Possessing more than 100 employees,our company is devoted to 5 series of products with 200 ranges of specifications. We are pleased to introduce ourselves as the leading exporter in the industry that has passed ISO9001, ISO14001 and TUV (Technischer Uberwachungs Verein) quality management system certificates. Our company has set up a professional technical center engaged in numerous years Our Company has set up a professional technical center engaged in numerous yesrs... |
Q1: Can I get some samples?
A1: Yes, Sample order is available for quality check and market test .But you have to pay for it .
Q2: What’s delivery time?
A2: It usually takes about 3-5 working days for small order and 10-15 days for big order .
Q3: What’s your payment terms?
A3: We usually accept all kinds of payment terms .Such as T/T,L/C, Western Union.Cash.
Q4: What’s your warranty terms?
A4: We offer 12 months warranty time .
Q5: Do you have the products in stock?
A5: Depends on your request ,We have standard models in stock. Some special products and big order will be newly produced according to your order .
Q6: Can I mix different power in one container?
A6: Yes ,Different models can be mixed up in one container ,even one order .
Q7: How does your factory do the quality control?
A7: Quality is priority ,we always attach the importance to quality control from the beginning to the end of the production .every product will be fully assembled and carefully tested before packing and shipping .
Q8: Can you sell spare parts ?
A8: Yes,Of course .we can sell spare parts to you .
Q9: I would like to know if you have a partner for export?
A9: Yes .we have the right to export and can sell all product all over the world..
Q10: Can you make the new miner lamps?
A10: Yes. We have a lot of experience to design new wireless and wire miner lamp according to your request . It’s better to design as your wiring diagram .
Q11: How can I trust you ?
A11: The core of BOSHI culture is honesty and loyalty .our company has been audited and approved ISO9001,CE.CCC. Assessment report will could be sent to you by e-mail .also .We are China Alibaba gold supplier since 2007.Now we have clients all around the world .
