Help CenterIADC517 8 3/4 in TCI Tricone Bits for Geothermal Application
Related Products
-
IADC147 8 3/4" Milled Teeth Rock Bits for Gas /water Well DrillingUS$ 100 - 8,000MOQ: 1 Piece -
IADC135 5 1/4" Milled Teeth Rock Bits for Geothermal ApplicationUS$ 200 - 8,000MOQ: 1 Piece
-
Satisfied Good Quality 6 1/8" Single Cone Bits for DrillingUS$ 100 - 500MOQ: 1 Piece
-
6 1/4 ''IADC517 Tri-cone Bits/tri-cone Drilling Bits/tri-cone Rock BitsUS$ 1,000 - 10,000MOQ: 1 Piece
-
6 1/2 ''IADC517 Tri-cone Insert Bits/tri-cone Drilling Bits/tri-cone Rock BitsUS$ 1,000 - 10,000MOQ: 1 Piece
Specifications
ISO9001 certificationlong life
cost-effective
Advanced processing:forging
Advanced equipment
It can receive higher WOB and faster rotary speed than conventional roller bearing bits.It is suitable for high RPM applications.
IADC |
WOB(KN/mm) |
RPM(r/min) |
Applicable Formations |
417/427 |
0.3-0.9 |
150-70 |
very Soft formation with low compressive strength and high drillability,such as clay,soft mudstone,shale,salt,loose sands,etc. |
437/447 |
0.35-0.9 |
150-70 |
very Soft formation with low compressive strength and high drillability,such as clay,soft mudstone,shale,salt,loose sands,etc. |
515/525 |
0.35-0.9 |
180-60 |
very Soft formation with low compressive strength and high drillability,such as mudstone,salt,soft limestone, sands,etc. |
517/527 |
0.35-1.0 |
140-50 |
Soft formation with low compressive strength and high drillability,such as mudstone,salt,soft limestone,sands,etc |
535/545 |
0.35-1.0 |
150-60 |
medium soft with harder formation, more abrasive streaks,such as hard shale,mudstone,soft limestone,etc. |
537/547 |
0.4-1.0 |
120-40 |
medium soft with harder formation, more abrasive streaks,such as hard shale,mudstone,soft limestone,etc. |
617/627 |
0.45-1.1 |
90-50 |
medium hard with higher compressive strength as well as thick and hard streaks,such as hard shale,sands,limestone,dolomite,etc. |
637 |
0.5-1.2 |
80-40 |
medium hard with higher compressive strength as well as thick and hard streaks,such as hard shale,sands,limestone,dolomite,etc. |
737 |
0.7-1.2 |
70-40 |
Hard with high abrasiveness such as hard limestone,dolomite,firm sands,etc |
827/837 |
0.7-1.2 |
70-40 |
very hard with high abrasiveness,such as quartzite,quaruzite sand,chert,basalt,granite,etc. |
Other products:
- Hejian Hengji Bit Manufacture Co.,Ltd is established in 2012.It is located in hejian,hebei province.It is emerging enterprises in Chinese bit industry.It is mainly engaged in the development,production and sales of all kinds of bits.
- It has developed and mass-produced products 3 to 26 inches series steel tooth bits and tricone bits,various types of PDC bits,core bits and production and processing assembly 0.6m to 3 m large diameter drill bits.
Perfect after-sales service
Supply use and maintenance support
Welcome to visit our company and inquire any other question, We will answer your questions in detail
