Home > Products > Steel Wire > Galvanized, Electro Galvanized, Hot Dipped Galvanized Type and is Alloy Alloy or Not Galvanized Steel Wire
Galvanized, Electro Galvanized, Hot Dipped Galvanized Type and is Alloy Alloy or Not Galvanized Steel Wire
- SHANGHAI
- T/T
You May Like
Product Details
| Steel Grade | steel | Standard | AISI, ASTM, BS, DIN, GB, JIS | |
| Wire Gauge | 1.24-5.50mm | Place of Origin | Zhejiang, China | |
| Type | Galvanized | Application | Manufacturing | |
| Alloy Or Not | Non-alloy | Special Use | Cold Heading Steel | |
| Model Number | galvanized wire | Brand Name | WANSHENG |
Product Description
galvanized, electro galvanized, hot dipped galvanized type and is alloy alloy or not galvanized steel wire
1.Material: 45,65,70, 72A, 72B, 82B, 65Mn
2. Surface Coating: Galvanized
3. Characteristic: High tensile strength,small tolerance
Shiny surface, good corrosion prevention
4. Packing type:Spool; Coil
5. Application: Being used for stranded conductors in overhead power circuitry
6. Remarks during use and handling:
a. During transportation, handle softly and carefully, avoid bumping and damaging the steel wires. Moisture and rain prohibited. Steel wires must be stored in dry and well ventilated indoors
b. Pay attention to the direction of steel wires when paying-off. Be sure the spools or coilis rotationg freely as to achieve identical tension of all the steel wires
c. In case of batch usage, the remaining should be repacked to avoid oxidizing of the surface to guarantee coating
Technical parameters
Wire dia: 1.24-5.5mm; Tensile Strength:1340~1290Mpa
Nominal Diameter | Tensile Strength | Stress at 1% Elongation | Twist | Elongation | Standard |
mm | Mpa | Mpa | Times/360°C | Lo=250mm | As per GB,EN,IEC,JIS,ASTM standard,as well as customer's request |
1.24-2.25 | ≥1340 | ≥1170 | ≥18 | ≥3% | |
2.25-2.75 | ≥1310 | ≥1140 | ≥16 | ≥3% | |
2.75-3.00 | ≥1310 | ≥1140 | ≥16 | ≥3.5% | |
3.00-3.50 | ≥1290 | ≥1100 | ≥14 | ≥3.5% | |
3.50-4.25 | ≥1290 | ≥1100 | ≥12 | ≥4% | |
4.25-4.75 | ≥1290 | ≥1100 | ≥12 | ≥4% | |
4.75-5.50 | ≥1290 | ≥1100 | ≥12 | ≥4% |
NOTE:Providing engineer design as per customer's request.
