Fiberglass Gpo-3 insulation sheet
- 5000 Kilogram / Kilograms per Month
- Shanghai
- T/T Credit Card
You May Like
-
Gpo-3 sheet polyester fiberglass sheet
-
Gpo-3 insulation sheet With UL certificate
-
Gpo-3 Laminates Sheet colored Red
-
GPO-3 rods insulation heat resistance used in electric equipment
-
High Quality UPGM-203 Gpo-3 Halogen-free insulation parts rods tubes
-
Gpo-3 insulation laminated panel sheet polyester fiberglass sheet color red
Product Details
Place of Origin | China | Brand Name | szwanrun | |
Model Number | Gpo-3 | Type | Insulation Sheet | |
Material | Fiberglass | Application | High Voltage | |
Rated Voltage | 110000v | Tensile Strength | 150MPa |
Product Description
1.Type:GPO-3
2.Size:1020*2040mm
1000*2000mm
3.Thickness: 1-50mm
lor: red & white
GPO-3 is alkali-free fiberglass mat dipped into unsaturated polyester resin adding relevant chemical agent as the basic material pressed under high temperature into rigid panel insulating material.
It is also called as UPGM203 and suitable for mechanical and electrical usage.
GPO-3 has good electrical property under high humidity and high mechanical property under medium temperature, fire retardant property, good arc resistance and tracking resistance.
Its widely used in the low voltage electrical industry in the European and American countries.
Properities
Process and production,According Our Client’s delivered drawing and samples.
Any needs, please don’t Hesitant to let me know freely.
Your Reliable partner For Insulation Material provision.
- As one of the leading manufacturers of insulation material,we put the quality at first. And we will on line for 24 days for your inquiry.
- We have our senior engineers team and introducing the advanced technology and equipment to make products according to costomer drawing ,data ,or samples and so on.
Our office
Our Factory
1.Q:What about the package of product?
A:1. Wooden pallet with carton. 2. Plastic pallet with carton. 3. Wooden wooden pallet with wooden case. 4. According to customer requirements.
2.Q:What's the payment?
A:30%TT advance , 70% after send the copy of the BL.We accept T/T,L/C, Western Union ,USD.
3.Q:If I need sample,what should I do?
A:It's our pleasure to send sample for you.You can send me your delivery address by email or message.We will send you free sample at first time.
4.How can you deal with quality issues that customer feedback after receiving the goods?
A:
1).Customers take photos of unqualified goods and then our sales staff will send them to Engineering Department to verify.
2) .If the issue is confirmed, our sales staff will explain the root cause and take corrective actions in coming orders.
Please FEEL free to contact us.
