China's Use of Sawdust Hammer Mill

China's Use of Sawdust Hammer Mill photo-1
China's Use of Sawdust Hammer Mill photo-2
China's Use of Sawdust Hammer Mill photo-3
China's Use of Sawdust Hammer Mill photo-4
China's Use of Sawdust Hammer Mill photo-5
China's Use of Sawdust Hammer Mill photo-6
US$ 4,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, wood chips and sawdust making
Use:
wood crushing
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or other china port as request
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, wood chips and sawdust making
Use wood crushing
Power Type Diesel
Production Capacity 2-3t/h
Place of Origin Henan, China
Brand Name Sharingmachine
Model Number HSXP800(Portable)
Dimension(L*W*H) 2000*1500*1800mm
Weight 2050
Certification CE ISO
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas



China's extensive use of wood crusher machine and diesel engine
sell

Introduction of China's use of sawdust hammer mill

The wood crusher produced by our company is a kind of newly-developed wood crushing equipment for raw wood and other agro-forestry on the basis of  traditional crusher making theories both home and abroad. It is composed of machine body,

knife chipping part, chips re-crushing part and sieving part, etc. It combines both chipping and crushing in one machine,

can make sawdust in one passage, no need to use wood chipper for preprocessing of wood logs.The size of finished

material is determined by adjust the length of blade and the diameter size of sieve, so as to satisfy different requirement.



It is widely applied in paper-making factory, forestry industry and other wood processing factories by producing edible

fungus, or sawdust board raw material, man-made charcoal raw material, paper-making material, etc.



China's use of sawdust hammer mill



Advantages of malaysia wood crusher machine diesel engine:



1. Driving system can be diesel engine or motor according to clients need


2. Installed with wheels which is portable


3. High crushing output


4. High-quality finished products (The size of finished materialis determined by adjust the length of blade and the diameter

 size of sieve, so as to satisfy different requirement 0-20mm.)


5. Easy to operate and maintain


6. To ensure security, the feed inlet of this machine adopts self-suction design to
avoid serious damage to operators.


8. Low investment and energy consumption





Technical Data of China's use of sawdust hammer mill



ModelHSXP260(Portable)HSXP800(Portable)
Diesel engine18 HP (Or 11.0kw) 28 HP(Or 22.0kw)
Capacity1-1.5t/h 2-3t/h
Max diameter of wood log allowed 80mm 200mm
Crushed wood chips size 2-20mm (adjustable) 2-20mm (adjustable)
Diameter of cutter head 260mm 800mm
Max rotary diameter of cutter head 380mm 980mm
Rotray speed of cutter head 3000r/min 2000r/min
Quantity of cutting knife 2 pieces 4 pieces
Quantting of cutting blade 16pieces 36pieces
Weight  1050kg 2050kg
Dimension 2000*1300*1200mm 2000*1500*1800mm



China's use of sawdust hammer millChina's use of sawdust hammer millChina's use of sawdust hammer millChina's use of sawdust hammer mill

China's use of sawdust hammer millChina's use of sawdust hammer millChina's use of sawdust hammer millChina's use of sawdust hammer millChina's use of sawdust hammer millChina's use of sawdust hammer mill

China's use of sawdust hammer millChina's use of sawdust hammer millChina's use of sawdust hammer mill

If you want to China widely used diesel engine crusher machine, please feel free to contact me as follows:



China's use of sawdust hammer mill
