Professional bbq coconut charcoal briquette making machine with low cost

 1. Introduction of  bbq coconut charcoal briquette making machine

This punching type briquette machine is mainly used to press coal/charcoal/coke and some mineral powder into briquettes in honeycomb shape, round shape, square shape, hexagon shaped and etc with high density and standard shapes, we can customize the mold to reach your final product request,.

It has been popularly used in China for almost 80 years. Previously raw coal been processed into the coal sphere slightly larger than ping-pong, and later the coal processed into one cylinder, and marked with a number of holes inside the cylinder makes it seems like honeycomb, because it can increase the surface area of coal, so that the full combustion of coal, to reduce resource waste. Mostly it is used in coal, metallurgical powder, powder cold-pressing ball, refractory materials (for burning and house heating etc...)

This punching type briquette press machine is applied to make briquette from coal fine or charcoal powder or chemical dust, mineral dust, coke powder,etc.  Size of briquette can be 30 mm - 260 mm, shape of briquette is custom designed. The finished product can be widely used in many fields, such as BBQ, home cooking, steel industry, the greatest merit of them is to be easily ignited by a lighter, very convenient, also, their burning time is very long.

 2. Working of  bbq coconut charcoal briquette making machine

Loading prepared material into the hopper, distributor will feed material into the molds under the hopper, then the pressure device will press the powder, under the stronger press, powder will be formed to a certain shape. Next, the briquette will be pressed out off the mold by auxiliary punch, and fall on the belt conveyor. With the rotating of dieplate, this process will be continuous.

 3. Features of  bbq coconut charcoal briquette making machine

1. Each machine can be equiped with many moulds by customizing the related shapes, it means you can produce different kinds of honeycomb briquette by a single one machine, the shape of final briquettes can be square, round , hexagonal, cylindrical, etc.

2. Spline structures and fully enclosed gear reducer make sure our machines accurate pointing, Rational structure, smooth operation, low voice, energy saving.

3.With our self researched formula, the briquette is smokeless,.high density and easy to be ignited.

4. Multi-used: Not only process coal powder into coal briquettes,but also minaral materials and biomass wastes.With the development of charcoal making technology and people's awareness of the environment, many bio-waste such as coconut shell, bamboo, wood branches, straws etc can all be carbonized firstly, and then crushed into charcoal powder, then the charcoal briquette machine can be used for make charcoal briquette which is no smoking or smell and burning longer.

4. How to choose  bbq coconut charcoal briquette making machine

At the first time you see the model 140, you may do understand what does that mean . Let me tell you , it means that the Max. diametes of the briquette made by this machine is 140mm . Yes , next time you see model 160 , you will know that it's biggest diameter of the honeycomb briquette is 160mm . While , how many wholes should be on the briquettes depending on you , ( usually it is 9 or 12 holes or as your request ).

5. Production line of of  bbq coconut charcoal briquette making machine

Apart from the Punch type briquette making machin, other related machine such as feeder, grinder, crusher, conveyor and dryer are also available in our factory, it means we can offer a whole product line. In addition, we can help you with the installation.

Raw material-----Crushing -----Mixing-----Feeding-----Briquetting----Final briquette

6. Our service of  bbq coconut charcoal briquette making machine

The Pre-sale service is free, begins with analyzing and planning of your particular needs. Whether you need a single machine, a multi-stage process? Or a production line of complete plant. Henan Machine Co.,Ltd.can advise you on the right solution for the most cost-efficient briquetting.

We can guide you to install the products or directly send our engineer in your country for the installation.

In the after sales service, Henan Sharing International Trade Co., Ltd has a team of briquetting professionals ready to help you. We provide one year warranty for all of our products and six month for the wear parts. Spare and wear parts are always close to you.

7. Other details for cooperation to build  bbq coconut charcoal briquette making machine

1. 1.     Payment :30% TT in advance, 70%TT balance pay off before delivery.
2. 2.     Packing: The machine and wear parts will protected by plywooden box or as customers’ will.
3. 3.     Delivery time: For one set, the delivery time is 7-10 days, for 1-5 sets 20-25 days, above 5 sets usually negotiate.
4. 4.     Shipping company: MSK/MSC/APL/EMC/WANHAL/KLINE and We will remind you before boat arrive and offer you all the customs clearance documents on time.

8. Contact information for more details of  bbq coconut charcoal briquette making machine

All of our Henan Sharing International Trade Co., Ltd appreciate for your interest in our machines and please contact us freely if you have any questions or requirements by the following contact information. Your visit of our factory to test the machines you like will be warmly welcomed. Hope to have the honor to cooperate with you in the bright future.

Note: if you do not get your target briquette making machine type, please click the below picture to get your target briquette machine.
