5ml.10ml.20ml High Speed Ampoule Vaccine Injection Equipment
Significant characteristic
1.Comply the weighing detection and automatic feedback information to adjust the unit during the whole procedure. This function avoided the undertected and cross-contamination happened on the same filling and sealing machine when get blank for weighing then put back for filling, the get bottle for weighing then put back for closing.The function effectively suppresses filling errors and cross-contamination.
2. Apply the linear stopper closing which is conducive to laminar flow, which completed avoided the rotary stoppering plate stop the laminar flow and the cross-contamination cauused by the whirling mixed flow, much meet the new GMP requirements.
3. table suraceis simple, no dead space and easy for cleaning
Picture introduction
Optional items
1. Restrict entrance system (RABS C-RABS)
2. Shield (ISOLATER)
3. Wind speed , air pressure, dust, particles, lanktonic bacteria on-line detection
4. On-line photographic detection and removing of unqualfied stoppering
5. Full on-line weighing system
6. Capping device
Main Technique Parameter
| Container size | Glass type plastic vial infusion bottle | Volume:1-500ml |
| Diameter:14-86mm | ||
| Height:30-180mm | ||
| Applicable products | water injection,lyophilized injection powder,infusion medicine and other solution of non terminal sterilization type terminal sterilization | |
| filling error | ≤±1% | |
| Model | filling heads | stoppering heads | capping heads | max capacity(b/h) |
| KGF4/2 | 4 | 2 | 2 | 8000 |
| KGF8/4 | 8 | 4 | 4 | 16000 |
| KGF12/6 | 12 | 6 | 6 | 24000 |
| KGF16/8 | 16 | 8 | 8 | 32000 |
Shipping and Payment
Packing |
Export standard package |
MOQ |
1 set |
FOB price |
Please contact for new price |
Delivery time |
60days |
FOB port |
Shanghai |
Payment terms |
T/T,L/C at sight |
