Ampoule Washing Sterilizing Filling and Sealing Production Line
Main usage:
This production line is made up of CLQ vertical ultrasonic washing machine,RSM drying &sterilizing machine,AGFfilling &sealing machine ,which can complete the following functions of ultrasonic washing,rinsing ,air-charging,siliconizing,drying&sterilizing, cooling,filling,sealing
Characteristics:
It adopts advanced ultrasonic washing ,alternating flushing with multiple needle separately ,laminar flow hot air drying &sterilizing ,laminar flow purifying,multiple-needle filling , sealing.It is characterized by compact structure,small occupying area, high automation ,fewer operator. It adopts photoelectric technology, servo motor,PLC and color touch LCD screen control system. with high automation ,fewer operator .
It is suitable for ampoule with different specifications and wide compatiblity,easy to exchange specification parts.
Main techncial parameter:
Model |
Single machine |
Suitable size |
Capacity |
Power |
(Kg) Net weight |
(mm) Overall dimension |
BXAZ1/20 |
CLQ100 |
1-20ml |
1-2ml :30000pcs/ |
60Kw,30Kw 60Kw,Real consumption:30Kw |
7000 |
9200*2100*2600 |
5ml:21000pcs/h | ||||||
10ml:17000pcs/h | ||||||
RSM620/38 | ||||||
20ml:12000pcs/h | ||||||
AGF10/1-20 | ||||||
BXAZ1/10 |
CLQ120 |
1-10ml |
1-2ml:36000pcs/h |
84Kw actual consumption 44Kw |
8000 |
10400*2300*2600 |
RSM900/60 |
5ml:25000pcs/h |
|||||
AGF12/1-10 |
10ml:20000pcs/h |
Shipping and Payment
Packing |
Export standard package |
MOQ |
1 set |
FOB price |
Please contact for new price |
Delivery time |
60days |
FOB port |
Shanghai |
Payment terms |
T/T,L/C at sight |
