China Hydraulic Sesame Oil Machine With Hight Oil Pressing-rate

China Hydraulic Sesame Oil Machine With Hight Oil Pressing-rate photo-1
China Hydraulic Sesame Oil Machine With Hight Oil Pressing-rate photo-2
China Hydraulic Sesame Oil Machine With Hight Oil Pressing-rate photo-3
China Hydraulic Sesame Oil Machine With Hight Oil Pressing-rate photo-4
China Hydraulic Sesame Oil Machine With Hight Oil Pressing-rate photo-5
China Hydraulic Sesame Oil Machine With Hight Oil Pressing-rate photo-6
US$ 3500.00 - 3500.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Sesame Oil
Type:
Other, Cold & Hot Pressing Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao / tianjing/ shanghai or as clients' need
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Usage Sesame Oil
Type Other, Cold & Hot Pressing Machine
Automatic Grade Automatic
Production Capacity 100%
Place of Origin Henan, China
Brand Name SHARING MACHINE
Model Number HSO-230
Voltage 220V/380V/440V
Power(W) 1.5kw
Dimension(L*W*H) 800*650*1100mm
Weight 880kg
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

 China hydraulic sesame oil machine

with hight oil pressing-rate





Brief introduction of    hydraulic sesame oil machine :

The machine is suitable for cold pressing or hot pressing any oil seeds and oil plant,

such as olive, sesame seeds, palm kernel, pumpkin seeds, cashew, avocado, tiger nut, fruit seeds, etc.
Only one machine, you could get the better oil and easy to operate.



Main structure of   hydraulic sesame oil machine :

The machine is mainly composed of plunger, hydraulic cylinder, upright, flexible top, base, workbench,

feed cylinder, heating collar, fixing, oil tank etc.



Features of   hydraulic sesame oil machine :

Hydraulic oil press has many advantages: easy to operate, high oil press rate, rare to replace wearing parts,  compact structure,

low energy consumption reliable performance,etc.So this oil press is the most advanced equipment which can replace of the manual operation of the sesame oil.

This machine can press at 2 to 7 kilogram per batch, the time is about 6 to 10 minutes.



Technical parameter of    hydraulic sesame oil machine :

 Models

HSO-180

HSO-230

HSO-320

External Dimension(mm)

800*650*1100

900*750*1400

1100*1000*1500

Weight of machine

530kg

880kg

1320kg

Nominal pressure

1600KN

2200KN

3000KN

Max pressure for working

55Mpa

55Mpa

55Mpa

Power of electricity heating circle

1KW

1KW

2KW

Controlling temperature of heating circle

70-100°C

70-100°C

70-100°C

Sesame weight/time

1-3kg

2-7kg

5-15kg

Power(kw)

1.5kw

1.5kw

1.5kw





Raw Material

Mode

Oil Extraction Rate(%)

Time Period/time

Weight(kg)/time

10 hours processing capacity(KG)



Sesame



180



42%-52%



5-8min

1-3

150-300

230

5-8min

1-7.5

400-600

300

6-8min

1-15

1000-1200



Amonds



180



40%-45%



5-8min

1-2.5

150-250

230

5-8min

1-6

300-500

300

6-9min

1-14

800-1000

Walnuts



180



50%-60%



5-8min

1-2.5

150-250

230

5-8min

1-6

300-500

300

6-9min

1-14

800-1000

Its most effectiveness and profitability make it an ideal investment.

Pictures of   hydraulic sesame oil machine :

China hydraulic sesame oil machine with hight oil pressing-rate



China hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rate

China hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rateChina hydraulic sesame oil machine with hight oil pressing-rate



Thanks for your interested iChina hydraulic sesame oil machine with hight oil pressing-raten our  hydraulic sesame oil machine ! For more deatils, please contact us freely as below:

China hydraulic sesame oil machine with hight oil pressing-rate
