Meanwell 18w switched mode power supply/12 ~ 18W AC-DC Single Output Interchangeable Wall-mounted type /12v adaptor/ac dc switch Quality Choice

ORDER NO.

GE18I012-P1J

OUTPUT

SAFETY MODEL NO.

FRA018-S12-I

DC VOLTAGE         Note.2

12V

RATED CURRENT

1.5A

CURRENT RANGE

0 ~ 1.5A

RATED POWER

18W

RIPPLE & NOISE (max.)   Note.3

120mVp-p

VOLTAGE TOLERANCE       Note.4

±3.0%

LINE REGULATION       Note.5

±1.0%

LOAD REGULATION      Note.6

±3.0%

SETUP, RISE, HOLD UP TIME

4000ms, 100ms, 30ms / 230VAC 4000ms, 100ms, 10ms / 115VAC at full load

INPUT

VOLTAGE RANGE

90 ~ 264VAC     135 ~ 370VDC

FREQUENCY RANGE

47 ~ 63Hz

EFFICIENCY (Typ.)

82%

AC CURRENT

0.7A / 100VAC       0.4A / 230VAC

INRUSH CURRENT (max.)

COLD START 40A / 100VAC     80A / 230VAC

LEAKAGE CURRENT(max.)

0.25mA / 240VAC

PROTECTION

OVERLOAD

110 ~ 200 %rated output power

Protection type : Hiccup mode, recovers automatically after

 fault condition is removed

OVER VOLTAGE

115% ~ 135%

Protection type : Clamp by zener diode

ENVIRONMENT

WORKING TEMP.

-10 ~ +50°C(Refer to "Derating Curve")

WORKING HUMIDITY

20~90% RH non-condensing

STORAGE TEMP., HUMIDITY

-20~+85°C, 10~95%RH

TEMP. COEFFICIENT

±0.03%/°C( 0~ 50°C)

VIBRATION

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along

 X, Y, Z axes

SAFETY&EMC

SAFETY STANDARDS

UL60950-1, CSA C22.2, TUV EN60950 -1, CCC GB4943 approved

WITHSTAND VOLTAGE

I/P-O/P:4242VDC

ISOLATION RESISTANCE

I/P-O/P:100M Ohms /500VDC/25°C/70% RH

EMC EMISSION

Compliance to EN55022, EN61000-3-2,3, FCC part15, GB9254 class B

EMC IMMUNITY

Compliance to EN61000-4-2,3,4,5,6,8,11, light industry level, criteria A

OTHERS

LIFE

2 years : 100% load 30°C, 8 hours / day

MTBF

100Khrs min.    MIL-HDBK-217F(25°C)

DIMENSION

81*43*40.5mm (L*W*H)

PACKING

134g ; 60pcs / 12.32kg / CARTON

CONNECTOR

PLUG

Standard type P1J: 2.1 * 5.5 * 11mm turning fork type, center positive for stock ; Other type available by customer requested

CABLE

See page2

NOTE

1.All parameters are specified at 115VAC input, rated load, 25°C 70% RH ambient.

2.DC voltage: The output voltage set at point measure by plug terminal & 50% load.

3.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.

4.Tolerance: includes set up tolerance, line regulation, load regulation.

5.Line regulation is measured from low line to high line at rated load.

6.Load regulation is measured from 20% to 100% rated load

7.Main body unit and AC inlet plug should be ordered seperately ; it needs to be used along with any of the AC inlet plug.
