W8LC 12 Inch Outdoor Stage Sound System Pro Line Array Speaker

US$ 1 - 1,000 MOQ: 2 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

RKB

Model Number:

W8LC

Guangzhou Hongxiang Audio Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou or Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name RKB

Model Number W8LC

Product Description

Model: W8LC 12 inch outdoor stage sound system pro line array speaker

Features:

*W8LC is a passive three-way line array system, with refined and improved technic.

*The whole system is capable of forming a continuous, equiphase linear sound source.

*The speaker cabinet is easy to control the coverage.

*Extremely high sound pressure levels and long distance.

*High-protection water paint to make sure the durability of the cabinet, to prevent it from scratch or hit.

*Above the high-strength metal grille, there is high-transmission acoustic foam, to keep it away from dust and rain.

*Trapezoidal box design with the seamless gap between two cabinets.

*Super-wide dynamic range and high-resolution.

*Most suitable for modern stadium, square, live show, big conference hall, and academic hall.

Applications:

*Medium and large theaters/ Auditoriums

*Medium and large outdoor stadiums

*Medium and large music halls

*Medium and large conference center

*Medium and large touring sound system

Specifications:

Model	W8LC
Components	LF:1x12” MF:2x6.5” HF:3x1.73”
Frequency Response	60Hz - 18kHz(±3dB)
Sensitivity(1W/1M)	HF:109dB MF:106dB LF:103dB
Maximum Peak SPL	135dB
Rated Power(RMS)	HF:100W MF:200W LF:400W
Peak Power(PEAK)	HF:200W MF:400W LF:800W
Impedance(Ohm)	HF:12 Ohm; MF:16 Ohm; LF:8 Ohm
Crossover	/
Dispersion Angle(-6dB)	90H x 0-6V (-6dB); 120H x 0-6V (-12dB)
Connectors	2xNL8 Speakon
Riggings	Standard Rigging Attached
Enclosure Material	High-strength Plywood
Cabinet Finish	Germany Water Paint
Protective Grille	Black Perforated Steel with Acoustic Cloth on surface
Dimensions (mm)	3661007550
Net. W.	51.7 kg
