Specifications
wireless tv signal transmitter1.15 years experience
2.AGC&MGC
3.Dual PS.Dual fans
4.Factory price and stritct QC
Made in China Fiber Optic Wireless tv Signal Transmitter
JZOT83 series 1310nm optical transmitter is a type of top class optical transmitter with AGC function and Dual Power supply .
The height of the transmitter is IU, it can be mounted on the 19” frame conveniently.
The main devices adopt AOI, XT or Ortel DFB low noise which contains thermoelectric refrigerator, continuous wave laser.
The whole technical performance indexes reach the similar imported equipment standard, supplying quality long distance
transmission of images, figures or compressed digital signal to cable and telephone communications.
Functional Characteristics:
·Selects the imported high quality high linear, light isolation, The thermoelectric refrigeration and distributed feedback (DFB) laser
· Laser working temperature is controlled by microprocessor automatic ATC and APC power function, to ensure the optimal working performance DFB laser.
Precisely control the output optical power, which prolongs working life.
· The front panel status display all key control parameters (output power, laser light temperature, state power and laser bias current, etc.)
Technical parameter
Optical wavelength: 1310±20 mm
Laser type: DFB laser
Optical modulation way: direct optical modulation
Optical interface type: FC/APC or SC/APC
Frequency range: 47~862/1000Mhz
RF output level: 75~82dBμV
RF input impedance: 75Ω
Input Reflection loss: ≥16dB
C/ CTB: ≥60dB
C/ CSO: ≥65dB
Noise ration C/N: ≥51dB
AGC control range:±20 dB
MGC control range: 0~10dB
Power supply voltage:DC 12V/1A
The whole machine loss:≤ 8W
Appearance Size(Width x Height x Deepness): 140x90x26mm
1550nm Internal Optical Transmitter
Functional characteristics:
- Special custom ITU -T standard wavelength laser. Superior transmission index
- Specifically for improving 1550 CSO index system design of predistortion circuit
- SBS threshold is more than 16 DBM. Within a certain transmission distance,system can not do any changes. 1550 nm straight transmitter can instead of modulation transmitter to work outside
- The front panel LCD full status display temperature, the optical output power, laser power state machine laser bias current, etc.
- The RG45 network management interface, 19 "standard 1 u rack.
Technical Parameters:
Optical wavelength: 1550±15nm
Optical modulation way: Direct modulation
Optical output channel: 1 road or 2 road
Optical output power: 4~10 dB m
Frequency range: 47~862/1000Mhz
RF input level: 75±5dBμV
In- Band flatness: ±0.75 dB
RF input impedance: 75Ω
Input Reflection loss: ≥16dB
C/ CTB: ≥65dB
C/ CSO: ≥60dB
Noise ration C/N: ≥52dB
Power consumption:24W
Network management transponder: class 2
Appearance Size(Width x Height x Deepness): 483x355x44mm
Packing
(1) Foam + Carton Package
(2) Each unit size: 483*355*44mm
(3) 2pcs are packed in one big carton box
(4) as client's requirements, lable can be customized.
Quick Delivery ,we have established long relationships with the famous transport and logistics company to guranteen the fast deliever and low shipping cost.
1.Professional technical support
2.R&D team: 100
3.Operation microsoft ware
4.After-sale Service
Guarantee replacement:
a. Range: after sailing the product, we can guarantee replacement for quality problem when
it is operated in normal station (non-deliberate damage).
Time limitation: within three months after sale. Guarantee
b. Range: after sailing the product, maintain for quality problem when
it is operated in normal station (ask for cost on module, transformer, and casing, other
parts can be changed to new ones)
c.Time limitation: within from three months to twelve months after sale.
Maintenance
d. Range: assure the maintenance of our any product lifelong
e. Charge: only charge for the cost of materials
If the equipment is out of Xi’an, both parties share transport costs.
In the long-term practice, JZ has carried a sincere communication with the customers and
understanding of their needs. Choose JZ means that you can enjoy our best technical
support and service.
