Functional characteristics:
1. 5-1000MHz optimization circuit design.
2. With High sensitivity PIN receiver and digital pin (-6~ +2dBm), It can precisely display input optical power..
3.The lastest GaAs power enlargement technology and the C/N, C/CSO,C/CTB index to ensure the favourable
link circuit.
4. Each port are independently segmented by duplex filter, up singal for each channel is independently adjustable.
5. Network management function is available, it also has II-type net management responder.
Technical parameters:
Item |
Unit |
Specification |
Note |
down working bandwidth |
MHz |
47/87 ~ 862/1000 |
|
Input optical power |
dBm |
-6~+2 |
|
Optical wavelength |
nm |
1200~1600 |
|
RF Flatness in Band |
dB |
±0.75 |
|
Output reflection loss |
dB |
≥16(47~550MHz) / ≥14(550~862MHz) |
|
Link C/N |
dB |
>51 |
|
Link C/CSO |
dB |
> 60 |
|
Link C/CTB |
dB |
> 65 |
|
Output level |
dBμV |
104 |
|
Up working bandwidth |
MHz |
5~50 or 5~65 or 5~42 |
|
up output optical power |
mW |
0.5 ~ 4 |
|
Power loss |
W |
≤ 18 |
|
Dynamic range for Noise power ratio(NPR) |
dB |
≥ 20(DFB laser) (NPR ≥ 30dB)/ ≥ 15(FB laser) (NPR ≥ 30dB |
|
Picture:
We are manufacturer
1. We are "The Best Cooperation Partner" awarded by NXP Company; "Golden Customer" by American ORTEL Company.
2. We have imported top-level NXT, Samsung, Omron automaticly flow production line and imported detecting equipments such as Agilent,Tektronix,EXFO, etc.
3. We have exported products from 2004,our international market extends all over the word.
Our services:
1.Your inquiry related to our products or prices will be replied within 24hours.
2.Well-trained and experienced staffs to answer all your enquires in fluent English.
3.OEM & ODM, any your customized requirements we can try to help you realize.
4.Protection of your sales area ,ideas of design and all your private information.
5.3 years warranty.
