Functional characteristics:
1. Output ability can be customized according to user's need and requirement: 2 port distriduted output of RI type ≥ 98dBuv; 2 port distriduted output of RII type ≥ 140dBuv;
2. Adopting special optical receiver modular guarantees high working reliability.
3. With BBS modulated structure and reverse transmitter module.
4. With External waterproof 24V power supply working indicator, the devise is convenient to maintain.
Technical parameters:
Item |
Unit |
Specification |
Note |
down working bandwidth |
MHz |
47/87 ~ 862/1000 |
|
Input optical power |
dBm |
-7~+2 |
|
Optical wavelength |
nm |
1200~1600 |
|
RF Flatness in Band |
dB |
±0.75 |
|
Output reflection loss |
dB |
≥16 |
|
Link C/N |
dB |
>51 |
|
Link C/CSO |
dB |
> 60 |
|
Link C/CTB |
dB |
> 65 |
|
working level |
dBμV |
98(204 output) 102(110 main way)/ 104 (204 output) 108 (110 main way) |
|
Reverse RF input level |
MHz |
5~65 or 5~42 |
|
up output optical power |
mW |
0.5 ~ 4 |
|
Power loss |
W
|
≤ 18 |
|
Dynamic range for Noise power ratio(NPR) |
dB |
≥ 20(DFB laser) (NPR ≥ 30dB)/ ≥ 15(FB laser) (NPR ≥ 30dB |
|
We are manufacturer
Our services:
1.Your inquiry related to our products or prices will be replied within 24hours.
2.Well-trained and experienced staffs to answer all your enquires in fluent English.
3.OEM & ODM, any your customized requirements we can try to help you realize.
4.Protection of your sales area ,ideas of design and all your private information.
5.2years warranty.
