CATV FTTH AGC Optical Receiver
Usage:
It is used for catv fiber signal input and RF signal output in catv system
Product advantage
- 5-1000MHz optimization circuit design, frenquency bandwidth according to system customization.
- It adopts singleship monitoring machine state.
- With Precisely electric controling attenuation and equalization, the machine is precisely modulated and controled by press key in local district.
- PIN photoelectric convertion with high-responsivity guarantees high working reliability.
- LED display for input optical power
- EOC can be customized
- Input optical power: -10~+3dbm
- Output level: 106dBμV
Main technical parameter
Item |
Unit |
Index |
|
Forward bandwidth |
MHz |
47/87~862/1000 |
|
Input optical power |
dBm |
-10~+3 |
|
Optical agc range |
dbm |
-7~+2 |
|
output return loss |
dB |
15 |
|
RF flatness in band |
dB |
±0.75 |
|
C/N |
dB |
≥52 |
|
C/CSO |
dB |
≥63 |
|
C/CTB |
dB |
≥65 |
|
Output level |
dBμV |
2 way distribution 106 |
|
power supply adapter |
v |
DC12V/1.5A/1A |
|
Power loss |
w |
10 |
|
network transponder |
|
Optional |
|
EOC |
|
Optional |
|
size |
mm |
150*144*55 |
|
Ordering information:
- frenquency/ bandwidth : 47~862mhz or 47~1000mhz
- Output port: 1 port/ 2 port/ 3 port/ 4 port
- operating enviroment: Outdoor / indoor or other
- Module/Ic used: NXP/NEC/ Chinese Ic
- power supply request:
- Other features that customer's request
Our factory show:
Our service:
1.Your inquiry related to our products or prices will be replied within 24hours.
2.Well-trained and experienced staffs to answer all your enquires in fluent English.
3.OEM & ODM, any your customized requirements we can try to help you realize.
4.Protection of your sales area ,ideas of design and all your private information.
5. 1 years warranty.
Welcome your inquiry
