Vibrating Feeder
1. Main use
The feeder of this series produced by our company is linear grizzly vibrating feeder, which applies a manner of vibration generator, having the improve the mechanical performance and continuous working capacity. The product is usually applied to feed jaw crusher. It is widely used in the crushing and screening plant in the field of mineral processing, building materials, water conservancy, and chemical industry. For example, feeding and blending to the crushing, coal filtering, screening, transportation, packaging machines and so on.
2. Advantages
a. Heavy shock absorber design, firm structure and stable operation.
b. Perfect frame structure and large process capacity, Fine material fluidness and no blockage.
c. Coarse screening capacity
d. Continuous and uniform feeding capacity
e. Easy installation and maintenance
The processing capabilities listed in the form shall vary according to different working conditions.
Principal technical data
| Model | Max. feeding size (mm) | Capacity (t/h) | Electric motor power (kw) | Funnel size (mm) | Weight(kg) (excluding electric motor) |
| WQB-300×70 | 425 | 25-62.5 | 2.2×2 | 3000×700 | 1726 |
| ZSW380×95II | 500 | 96-160 | 11 | 3800×950 | 4713 |
| ZSW490×110II | 650 | 160-350 | 15 | 4900×1100 | 6098 |
| ZSW600×130 | 800 | 400-600 | 22 | 6000×1300 | 9086 |
| ZSW600×150 | 1000 | 600-1000 | 30 | 6000×1500 | 10006 |
| ZSW600×180 | 1200 | 800-1500 | 37 | 6000×1800 | 14038 |
| GZG1003 | 300 | 270-500 | 1.5×2 | 1000×2258 | 1380 |
| GZG1603 | 500 | 770-1200 | 2.2×2 | 1600×2503 | 2850 |
| GZG1803 | 600 | 800-1500 | 3.7×2 | 1800×2503 | 3380 |
