Home > Lights & Lighting > LED Interior Lighting > LED Down Light > High Quality 6/9/12/15w Ultra Thin Led Downlight

High Quality 6/9/12/15w Ultra Thin Led Downlight

Name: High Quality 6/9/12/15w Ultra Thin Led Downlight
Brand: JIZHONG
SKU: 117402437

High Quality 6/9/12/15w Ultra Thin Led Downlight thumbnail-1

High Quality 6/9/12/15w Ultra Thin Led Downlight thumbnail-2

High Quality 6/9/12/15w Ultra Thin Led Downlight thumbnail-3

High Quality 6/9/12/15w Ultra Thin Led Downlight thumbnail-4

High Quality 6/9/12/15w Ultra Thin Led Downlight thumbnail-5

High Quality 6/9/12/15w Ultra Thin Led Downlight thumbnail-6

High Quality 6/9/12/15w Ultra Thin Led Downlight photo-1

High Quality 6/9/12/15w Ultra Thin Led Downlight photo-2

High Quality 6/9/12/15w Ultra Thin Led Downlight photo-3

High Quality 6/9/12/15w Ultra Thin Led Downlight photo-4

High Quality 6/9/12/15w Ultra Thin Led Downlight photo-5

High Quality 6/9/12/15w Ultra Thin Led Downlight photo-6

US$ 3.99 - 5.99 MOQ: 5000 Pieces

Key Specifications

Get Latest Price

LED Light Source:

SMD2835

Warranty(Years):

2years

Input Voltage(V):

220

Contact Supplier Request Quote Chat Now

Shaanxi Jizhong Electronics Scien-Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source SMD2835

Warranty(Years) 2years

Input Voltage(V) 220

Lamp Power(W) 12

Lamp Luminous Flux(lm) 800

Lamp Luminous Efficiency(lm/w) 90

Color Temperature(CCT) Other, cool white, warm white, pure white

Working Temperature(℃) -10, 40

Working Lifetime(Hour) 25000

Lamp Body Material Aluminum

IP Rating IP65

Certification CCC, CE

Model Number JZ-DRA035-6G

Place of Origin Shaanxi, China

Brand Name JIZHONG

Essential Parameters

Luminous flux:	350lm
Beam angle:	120°
CRI:	≥80
Installation:	Embedded
Place of origin:	Xi’an
Voltage:	220V
Style:	Mordern
Power:	6w
Hole size:	Φ100mm mm
Average life span:	25000h h
Input voltage:	220v
Dimension:	3.5 mm
Customize:	Yes
Light source power:	6w
Type of light source:	LED
Application:	Home furnishing, hotel, office and others
Lamp house material:	PMMA,PC
Shape:	other
Transformer:	220-240VAC 50-60Hz
Base:	E27
Brand:	JZDC
Model:	JZ-DRA06-06G
Light color:	Warm white, pure white
Energy conservation rate:	3.0
Applicable ratings:	All ratings

LED Ultra Thin Down light

Simple &ultra thin design with high temperature white paint; Anti-oxidative and moisture proof features make the product more reliable.

Imported LGP with more than 95% conductivity enhances luminous efficiency and lighting effect.

High quality aluminum radiator is used to make sure the light can be cooled quickly.

PC material is applied for actuator shell with dust proof, pressure-resistant and high temperature resistant features; Easy installation and maintenance of light body and power module are guaranteed via buckle connection.

Name

Light

source

Working

environment

Installation

Rated

lifetime

Beam angle

Input voltage

Color

Ultra thin down light

2835

-10℃-40℃

Embedded

25000h

120°

220~240VAC 50-60Hz

white

Model	Specs	Slot size (mm)	Power (W)	Luminous flux (lm)	Color temp.	CRI	Lifetime (h)	Package
JZ-DRA035-6G	3.5		6	350	3000/4000/5700/6500	≥80	25000	30
JZ-DRA04-9G	4		9	550	3000/4000/5700/6500	≥80	25000	30
JZ-DRA06-10G	6		12	700	3000/4000/5700/6500	≥80	25000	30
JZ-DRA07-15G	7		15	800	3000/4000/5700/6500	≥80	25000	30

Company Introduction

JI ZHONG DIGITAL COMMUNICATION CO., LTD locates in Hi-tech New Industrial Zone No.1. It is a Hi-tech enterprise which provides researching, manufacturing, managing and serving as a whole. It includes several

functional departments, such as, technical researching department, soft ware researching department, testing department,

producing department, quality managing department and marketing department. Besides it owns various manufacturing ennvironment: several advanced full-automatic and visual imported production line, full auto infrared carried current welding production line, auto-finished plug-in card production line, production line of full-auto multi-temperature welding in peak wave, full-auto circled assemble production line and 200 sq. m. high-low voltage and high-low temperature aging room.

The main products are digital front part basic hardware, digital TV Set-Top-Box(STB), digital TV operation support software, of which includes MPEG-2 single and multi-way compressed encoder, TS receiver, trans-current multiplexer, data Scrambler, QAM modulator, QPSK modulator, transmit flow distributor, net adapter, DVB-S digital STB, DVB-C digital STB, DMB-T ground wireless STB, CAS (conditional access system), SMS (subscriber management system), DBS(digital broadcast system)
