Help CenterCinnamon Powder Hammer Mill
Related Products
-
Cookie Milling MachineUS$ 3,000 - 4,000MOQ: 1 Set -
Biscuit Grinding MachineUS$ 3,000 - 4,000MOQ: 1 Set
-
Flour Grinding MachineUS$ 3,000 - 5,000MOQ: 1 Set
-
Commercial SUS 304 Pulveriser MachineUS$ 4,000 - 6,000MOQ: 1 Set
-
Stainless Steel Chemical & Foodstuff Powder Grinding Machine Quality ChoiceUS$ 3,000 - 4,000MOQ: 1 Set
Main Application:Comprised of main frame, auxiliary machine and electrical control cabinet, this machine has such performances as winnowing, screen or mesh free, uniform size and continuous operation, and has reached the international advanced level, thus being widely used for material crushing in pharmaceutical, chemical and foodstuff trades etc..
Working principle:The material is fed into the crushing chamber by a screw conveyor, cut and crushed by high speed rotating blade and conveyed to the cyclone separator by means of negative pressure air conveyance before being discharged by bag type collector, and the dust is filtered and recovered by dust collector through filter barrel Having no dust flying during production, it can improve utilization rate of the material and reduce the cost of enterprise.
Technical Parameters:
Model |
Production capacity(kg/h) |
Inout size(mm) |
Output size(mesh) |
Total motor power(kw) |
Main speed(r/min) |
Overall dimension(mm) |
Weight(kg) |
WFJ-300 |
10-100 |
≤10 |
60-450 |
13.5 |
5800 |
4200*1200*2700 |
1000 |
WFJ-450 |
50-250 |
≤10 |
60-450 |
19.3 |
5200 |
4300*1350*2700 |
1500 |
WFJ-520 |
80-500 |
≤10 |
60-450 |
39.05 |
5000 |
7920*1480*3290 |
2500 |
WFJ-630 |
200-1500 |
≤10 |
60-450 |
75.3 |
4500 |
9500*1800*3730 |
3200 |
Plywood case
Quality is our life.
We will try our best to be your trustworthy supplier.
24 hours online and tel service.Quick response.
Be your strong backup.
Any suggestion,we will be appreciate and take into consideration.
