EYH Series Planetary Mixer

EYH Series Planetary Mixer thumbnail-1
EYH Series Planetary Mixer photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Planetary Mixer
Product Type:
Other
Contact Supplier Request Quote Chat Now
Jiangyin Hongda Power Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Mixer Type Planetary Mixer
Product Type Other
Application Powder
Place of Origin Jiangsu, China
Brand Name Hongda
Model Number 2D Series
Certification CE, ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. mixing tank without stirring paddle
2. planetary moving
3. mixing high tonnage material
4. turnover swing movement

Main Application :
The planetary mixer is suitable for the mixing of dry granule materials for pharmaceutical, chemical industries, etc., especially for the mixing of materials with high tonnage.

Working principle :
The mixing tank is a cylinder-shape barrel without any stirring device inside, which makes the self-rotation around its axis and also produces turnover swing movement around its plane axis synchronized, therefore, the target materials inside the barrel could be mixed diffusely and moveable, it is featured with short mixing time, good uniformity, big output, convenient to discharge, etc..

Technical Parameters :

Model Barrel volume  Max loading volume Max loading weigh Mixing time No.of rotation No.of swing rotation Motor power swing Motor power Overall dimension Weight
EYH-50 50L 25L 25kg 0-99min 20r/min 11.5r/min 0.55kw 0.75kw 900*730*950mm 115kg
EYH-100 100L 50L 50kg 0-99min 20r/min 11.5r/min 0.75kw 1.1kw 1365*810*1150mm 190kg
EYH-150 150L 75L 75kg 0-99min 20r/min 11.5r/min 1.1kw 1.1kw 1650*950*1250mm 210kg
EYH-200 200L 100L 100kg 0-99min 20r/min 7.5r/min 1.1kw 1.1kw 1850*1000*1340mm 285kg
EYH-300 300L 150L 150kg 0-99min 17r/min 7.5r/min 1.1kw 1.1kw 1800*1050*1450mm 340kg
EYH-400 400L 200L 200kg 0-99min 15r/min 7.5r/min 1.1kw 1.1kw 1950*1140*1550mm 545kg
EYH-600 600L 300L 300kg 0-99min 15r/min 7.5r/min 1.1kw 1.5kw 1990*1300*1650mm 1150kg
EYH-800 800L 400L 400kg 0-99min 12r/min 7.5r/min 1.5kw 1.5kw 2100*1350*1710mm 1600kg
EYH-1000 1000L 500L 500kg 0-99min 12r/min 7.5r/min 1.5kw 2.2kw 2500*1500*1850mm 1700kg
EYH-1500 1500L 750L 750kg 0-99min 10r/min 7.5r/min 3kw 4kw 2630*1670*2050mm 2000kg
EYH-2000 2000L 1000L 1000kg 0-99min 8r/min 5r/min 4kw 4kw 2840*1780*2170mm 2600kg
EYH-3000 3000L 1500L 1500kg 0-99min 6r/min 5r/min 5.5kw 5.5kw 3200*2100*2550mm 3500kg
EYH-4000 4000L 2000L 2000kg 0-99min 5r/min 3.7r/min 7.5kw 11kw 3670*2560*2980mm 4100kg
EYH-6000 6000L 3000L 3000kg 0-99min 5r/min 3.7r/min 7.5kw 11kw 4500*3900*3500mm 6100kg
EYH-8000 8000L 4000L 4000kg 0-99min 4r/min 3.7r/min 11kw 15kw 5000*3300*4000mm 7900kg
EYH-10000 10000L 5000L 5000kg 0-99min 3r/min 3.7r/min 11kw 18.5kw 5300*3800*4400mm 9500kg





EYH Series Planetary MixerEYH Series Planetary MixerEYH Series Planetary Mixer
