ND-F40/150 3 Sides or 4 Sides Sealing Automatic Onion Powder Packing Machine Quality Choice
- 30 Set / Sets per Month
- Tianjin port or others port
- T/T L/C D/P D/A Credit Card PayPal
- Maquillageplastic sealing heat shrink packaging machine Seal and shrink the film packaging machine
- Express deliverybox packing and paste sheet packing machine Box sealing and paste single package all-in-one machine
- Maquillagemembrane packing machine
- Bookseal the heat-shrink packaging machine Seal and shrink the film packaging machine
- Automatic Screw Counting Packing Machine
- Maquillagemembrane packing machine Gift packageseal and cut the packaging machine
Product Details
Condition: | New | Function: | Boxing, Filling, Labeling, Laminating, Sealing, Other, Boxing, Filling, Labeling, Laminating, Sealing, bag making, measuring, filling, sealing, code, counting | Application: | Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles, food additives, milk powder, bean powder, coffee powder, tea powder, |
Packaging Type: | Bags, Barrel, Bottles, Cans, Case, Foil, Pouch, Stand-up Pouch, Other, Bags, Barrel, Bottles, Cans, Case, Foil, Pouch, Stand-up Pouch, Sachet bag, Stick bag, Pouch bag,Vertical bag | Packaging Material: | Paper, Plastic, Other, Paper, Plastic, Foil, Filter or other heatable sealed composite film etc. | Automatic Grade: | Automatic |
Driven Type: | Mechanical | Voltage: | 220V/380V/110V; 50Hz/60Hz | Power: | 1.8 Kw |
Place of Origin: | Tianjin, China | Brand Name: | NEWIDEA | Model Number: | ND-F40/150 |
Dimension(L*W*H): | 900*700*1900 mm | Certification: | CE,SGS,SASO,FORM E, C/O | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. ND-F40 and ND-F150 is onion powder packing machine, the machine
finish bag making,measuring,filling, sealing, coding and counting full automatically.
2. The packing material is heat seal-able rolled packing film, the cost is lower.
3. Measure and fill with screw auger, it control the filling volume according to change auger rotary
cycles, with 1% error, the bag former and vertical/horizontal sealing finish bag forming.
4. Suitable for packing powder product for 5-40ml(if ND-F150, volume 30-150ml) bag packing.
1. Computer control, intelligent temperature control system, color mark tracking device.
2. Reasonable mechanical structure,main machine speed is controlled by worm gear motor and
frequency converter, easy to adjust speed.
3. Low noise, stable system, simple operation.
4. Double heating tubes, the temperature more average, to make more perfect bag.
5. All the contact part of the packing machine is made from SS304, clean and safe, easy for
cleaning.
6. With high output 4000-6000 bag/hour,good labor and power saver. The continuous running
make it very high efficiency.
Type | Bag Length (mm) | Bag Width (mm) | Packing Speed (Bag/hour) | Measuring Range (ml) | Voltage Power | Weight (kg) | Size (mm) | Sealing Methods |
ND-F40 | 55-110 | 30-80 | 2100-4800 | 5-40 | 220V/50/60Hz/1.8Kw | 300 | 900*700*1900 | 3 /4 Sealing |
ND-F150 | 80-140 | 30-130 | 2100-4200 | 30-150 | 220V/50/60Hz/1.8Kw | 300 | 900*700*1900 | 3/4 Sealing |
ND-F320I | 40-160 | 15-150 | 3000-5400 | 5-300 | 220V/50/60Hz/2.0Kw | 320 | 950*700*1800 | Pillow sealing |
ND-F320II | 40-160 | 15-150 | 3000-5400 | 5-300 | 220V/50/60Hz/2.0Kw | 320 | 950*850*1900 | 3 Sides sealing |
ND-F320Ⅲ | 40-160 | 15-150 | 3000-5400 | 5-300 | 220V/50/60Hz/2.0Kw | 320 | 950*850*1900 | 4 Sides sealing |
ND-F398 | 30-320 | 70-210 | 1800-3600 | 500(Max) | 220V/50/60Hz/1.8Kw | 350 | 1200*900*2000 | Standard pillow bag |
ND-F420 | 80-300 | 50-200 | 300-3600 | 150-1200 | 220V/50/60Hz/2.2Kw | 550 | 1320*950*1360 | Pillow bag/Gusset bag/Box bag Pillow bag with punch hole Gusset bag with punch hole |
ND-F520 | 80-400 | 150-250 | 300-3600 | 3000(Max) | 220V/50/60Hz/4.0Kw | 600 | 1150*1795*1650 | |
ND-F720 | 100-480 | 180-320 | 300-3000 | 6000(Max) | 220V/50/60Hz/5.0Kw | 700 | 1780*1350*1950 |
Optional Accessories:
Auger Feeder Bag Former Coding Machine
Finish Product Conveyor Screw Elevator Vacuum Feeder
1.8 years manufacture experience,strong R&D department.
2.Exported to more than 1000 customers from more than 50 countries.
3.We promiss machine keep working over 10 years in good working condition.Fewer easy
broken parts,easy to change.
4.Intelligent PLC control system,easy operate,more hommization.
5.One year guarantee time,lifelong free service,24 hours online service.
6.High output 6000 bags/hour,save energy & labor.
7.OEM,ODM and customized service.
8.CE ISO BV GMP certificates.
Machine packing inside is plastic films and outside is fumigation wooden case. Our wooden case is very strong,it can bear long time shipping on the sea.And machine with preservative film,it can stop the salt sea water enter into the machine and make the machne corrosion. |
8 years professional manufacture experience,your best choice. |
Newidea is still developing,and the products are also being innovated.Welcome our old and new customers to visit our factory and make the consultation.We will provide professional packaging solutions for you.
