Help CenterMPS-H100 Paywelder Welding Tractor With Lifting Function and Power Supply
Related Products
-
Expanding Mandrel Pipe BenderUS$ 100 - 10,000MOQ: 1 Unit -
Manufacturer Sells New Large Diameter Pipe Bending MachineUS$ 1,000 - 70,000MOQ: 1 Set
-
JRQ Series Pipe Welding PreheaterUS$ 1 - 15,000MOQ: 1 Unit
-
JRQ Series Flame Heater for Pipe WeldingUS$ 1 - 15,000MOQ: 1 Unit
-
JRQ Series Pipe Preheating ToolUS$ 1 - 15,000MOQ: 1 Unit
Specifications
powerful cross-country performance crawler-type mobile generator sets, welding tractor of strong reliability and durability1. “MPS-H Series” all-hydraulic welding tractor is the special pipeline construction equipment, which has power saving, high efficiency and powerful cross-country performance, be able to perform in severe working conditions such as swamp, desert, ect, also it functions of all generating, traveling, welding, lifting ability
2. Patented design of rigid straight connecting of engine, generator and hydraulic pump for welding tractor.
Patent: ZL201120343299.2 ZL201020151740.2 ZL201030132252.2
ZL201120313312.4 ZL201020151736.6
3. MPS-H80 welding tractor with powerful cross-country performance supported by 10T excavator chassis with ship type platform frame and 91KN powerful traction
4. Compared with similar products, our welding tractor has an 11.2% improvement in efficiency, also cantilever crane equipped an independent hydraulic system, full rotating 360°ability.
5. Comfortable operating space for welding tractor :safe and low vibrating of YF-3 operating cab.
6. Reducing maintenance cost for welding tractor:incorporate engine, generator with hydraulic pump
7.Convenient turning operation for welding tractor :platform body is equipped with the built-in lifting hook, easy hoisting and shipping.
8. MPS-H100 welding tractor can supply electricty power to 4 units of MILLER welding machine. Also we recommand MPS-H80 which can supply power to 2 units of MILLER welder.
9.Any further questions,pls feel free to contact Fiona or visit our web
| Model | MPS-H100 | |
| Operating Weight | 11500Kg | |
| Overall Dimensions (L x W x H) | 5500 x 2600 x 3050mm | |
| Engine | Type | Cummins 6BTA5.9-C180 Turbo-charged, Water Cooling |
| Power | 132kw (at power generating condition: 121KW/1500rpm) | |
| Rotating Speed | 2200rpm | |
| Generator | Type | Faraday Generator FD3A (50hz/1500rpm) |
| Rated Power | 100kw | |
| Rated Capacity | 125kva | |
| Output Type | Three phases 380v | |
| Operating Format | Pressure/ Flux | 25mpa/189 L/Min |
| Traveling | Indoor hand & foot synchronization joy stick | |
| Generating | Indoor positioning joy stick | |
| Lifting | Outdoor joy stick | |
| Travel | Travel Speed(Front & reverse) | 2.8/4.6km/h (two shifts ,continuously variable transmission) |
| Grade ability | 30° | |
| Ground Pressure | 33/25 Kpa 39/32 Kpa | |
| Chassis | Minimum Ground Clearance | 490mm |
| Track Shoe Width | 500mm/600mm | |
| Cantalever Lift | Type | Hydraulic 360°swing ,telescopic boom |
| Max Lifting capacity | 3200kg | |
| Crane Radius | 2100-5320mm | |
| Pressure /Flux | 20mpa/25L/Min | |
| Main Carrying Capacity | DC400 4 units of Lincoln welding machine: 4 units of handwheel polisher (Factory setting: this equipment doesn't carry above items) |
|
