Specifications
1.powerful cross-country performance2.oil saving 11.2% comparied with similar products
fortable operating space
Model | MPS-H80 | |
Operating Weight | 10300Kg | |
Overall Dimensions(L*W*H) | 5500*2600*3050mm | |
Engine for Traveling | Type | Cummins 6BTA5.9-C170,turbo-charged, water cooling |
Power | 125kw | |
Rotating Speed | 2300rpm | |
Operating Format | Pressure/ Flux | 25mpa/189 L/Min |
Traveling | Indoor hand & foot synchronization joy stick | |
Lifting | Outdoor joy stick | |
Travel | Travel Speed(Front & reverse) | 2.8-4.6km/H(two shifts ,continuously variable transmission) |
Grade ability | 30° | |
Ground Pressure | 33/25Kpa39/32Kpa | |
Chassis | Minimum Ground clearance | 490mm |
Track Shoe Width | 500mm/600mm | |
Cantalever Lift | Type | Hydraulic 360°swing ,telescopic boom |
Max Lifting capacity | 3200kg | |
Crane Radius | 2100-5320mm | |
Pressure /Flux | 20mpa/25L/Min | |
Main Carrying Capacity |
| DC400 2 units of Lincoln welding machine;2 units of handwheel polisher these mentioned machines are not provided with paywelder MPS-H80 |
1.All-Hydraulic welding work station has power saving, high efficiency and power cross-country performance, be able to perform in severe working conditions such as the swamp, desert
2.Power cross-country performance
compared with similar products the paywelder has an 11.2% improvement in efficiency
comfortable operating space
reducing maintenance cost
convenient turning operation
3.saving energy& protect environment
high effect&realiability
match with the military standard
Our 16 units of welding work station has been using in Xinjiang which keeps the better performance compared with other brands, also constant redesigning welding work station structure has get a degree which have proved its best performance onsite, for more information please kindly refer below information:
