Help CenterWelding Pipeline Machine
Related Products
Specifications
1.incorporate engine ,generator with hydraulic pump without gear box2 hydraulic clutch travling system
310T excavator chassis
1. Power unit:It adopts the Cummins engine and Stamford generatoe.
2. It is less oil consumption, low noise, high effect reliable performance and stable generating;
3. Travelling system :it applies the open hydraulic system with full power variation. Main components are selected world-famous brands hydraulic components.
4. Operating system:it is the servoguide operating system, which is to be conveniently operated, accurately control. It can reach the continuously variable transmission with two shifts;
5. Chassis:it applies the all-steel ship frame with high intension
Model |
MPS-H100 |
||
Operating Weight |
11500kg |
||
Overall Dimensions(L*W*H) |
5500*2600*3050mm |
||
Engine |
Type |
Cummins 6BTA5.9-C180 Turbo-charged, Water Cooling, |
|
Power |
132KW(at power generating condition:121KW/1500rpm) |
||
Rotating Speed |
2200 rpm |
||
Generator |
Type |
Faraday Generator FD3C(50hz/1500rpm) |
|
Rated Power |
100 kw |
||
Rated Capacity |
125 kva |
||
Output Type |
Three phases 380v |
||
Operating Format |
Pressure/ Flux |
25mpa/189L/Min |
|
Traveling |
Indoor hand & foot synchronization joy stick |
||
Generating |
Indoor positioning joy stick |
||
Lifting |
Outdoor joy stick |
|
|
Travel |
Travel Speed(Front & reverse) |
2.8/4.6km/h (two shifts ,continuously variable transmission) |
|
Grade ability |
30° |
|
|
Ground Pressure |
33/25Kpa 39/32Kpa |
|
|
Chassis |
Minimum Ground Clearance |
490mm |
|
Track Shoe Width |
500mm/600mm |
|
|
Crane |
Type |
Hydraulic 360°swing ,telescopic boom |
|
Max Lifting Capacity |
3200kg |
|
|
Crane Radius |
2100-5320mm |
|
|
Pressure /Flux |
20mpa/25L/Min |
|
|
Main Carrying Capacity |
DC400 4 units of Lincoln welding machine; 1 unit of 7.5KW air compressor and 4 units of hand wheel polisher This equipment excludes the above items |
|
|
