2.5meter UV Flatbed printer

Specifications

maximum print size 2.52m*1.6m,max.
printheight 8 cm,
white color is optional

ZY-UV series UV flatbed printer adopts Japanese Seiko 255/12PL series printheads, equipped with double servo drivers,10cm max printing height.Realize the formless non-contacting and real-time printing on different kinds of sheet materials ,such as KTborad, PVC board, plexiglass,glass,ceramic,metal,and leather etc.it replace the roll of traditional screen printing technology,and brings to customers the individualized ,small-lot,various,and multicolored products,with the output features of speediness,high efficiency and flexibility guaranteed.









Name:	SKUV2518B
Class:	ZY-SKUVB series
Print technology:	Drop-on-demand Piezo electric
Printhead:	4/5/6/7/8/10/12/14 pcs (seiko spt255), Quantity of print head is optiional
Print width:	2.52M*1..52M
Print high:	10cm
Resolution:	1440dpi max
Speed:	2pass 24 M2/h ; 4pass 15 M2 /h ; 6pass 6 M2 /h
Locating mode:	Raster /servo
Color:	C M Y K W
Media width:	2.5M*1.6M
Media handl:	Sheet to sheet
Media types:	Wood,KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc
Drying system :	Uv lamp
File format:	TIFF,Postscript 3,JPEG,EPS,PDF
Working process:	Printmon software for windows xp
Rip:	Photoprint /maintop
Power supply:	50hz/60hz 220v(10%)20A
Operation environmeng	(Tempperature )18-26     (Humidity )         40%-70%
Dimesion:	4.7m*2.3m*1.66m
Weight:	1200 Kg





Ink reservoirs:         Refillable on the fly while printing

Ink characteristics      UV Curable Inks

Printhead controls      Print head temperature and voltage are software adjustable

Media feeding system:   Free spin/motor-driven lazy loop for optimal banner tension

Media take-up system   Automatic motor-driven spool 60m(200’) capacity

Warranty:             2 year

More different sizes and models available

Have got CE certificate
