diamond dressing roller grinding wheel for piston ring

Specifications

electroplated
Diamond dressing roller High dressing efficiency
Good profile consistency
Stable workpiece quality

Products for Automotive Industry:





Diamond dressing rollers for high precision form grinding



Main features:

High dressing efficiency

Good profile consistency

Stable workpiece quality



Application:

They are widely used for dressing the grinding

wheels  for processing screw of steering gear, universal joint, valve, bearing inner and outer raceway, camshaft, crankshaft and connecting rods and so on



We can produce high precision dressing rollers with inner galvanizing (UZ) methods. For example, we can supply complicated multi-teeth rollers with small radius R0.1and teeth distance less than 1mm and heavy grinding rollers with height more than 200mm and height diameter ratio bigger than 1.5.

Our  dressing rollers produced with outer galvanizing methods are used for dressing vitrified CBN grinding wheels and internal mounted points. Its features are high dressing efficiency and good straightness.
