ZY-Large Format Solvent Printer:3200 Series

ZY-Large Format Solvent Printer:3200 Series thumbnail-1
ZY-Large Format Solvent Printer:3200 Series photo-1
US$ 10,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Screen Printer
Place of Origin:
Liaoning, China
Contact Supplier Request Quote Chat Now
Liaoning Zhongye Technology And Industry Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Screen Printer
Place of Origin Liaoning, China
Brand Name Zhongye
Model Number ZY3200
Usage Other, vinyl sheet and carpet paper,flex banner, pvc, mesh fabrics.etc advert, roll to roll solvent printing
Automatic Grade Automatic
Voltage 220V
Gross Power 50hz/60hz 220v(10%)20A
Dimensions(L*W*H) 4.8m*1.4m*1.5m
Weight 500kgs
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

3.2M large format solvent printer
1, 4/8/12/16 (xaar128/40) print head
2, panasonic motor equipped
3, real 1440dpi

Name 3200
Class ZY-XR series
Print technology Drop-on-demand Piezo electric
Printhead 4/8/12/16 (xaar128/40)
Print width 3.2M
Resolution 720dpi max
Speed 2pass 60m/h ; 4pass 35m/h ; 6pass 18m/h
Locating mode Raster /servo
Color CMYK LC LM
Media width 3.2M
Media handl Roll to roll
Media types Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,etc
Ink  Solvent/two-year outdoor lifetime
File format TIFF,JPEG,Postscript 3,EPS,PDF
Working process Printmon software for windows xp
Rip Photoprint /maintop
Power supply 50hz/60hz 220v(10%)20A
Operation environmeng (Tempperature )18-26(Humidity )40%-70%
Dimesion 4.8m*1.4m*1.5m
Weight 550Kg/670Kg

ZhongYe XAAR series Large Format Solvent Printer: adopting xaar128/40 print head, DC motor&raster locating mode, cost-effective and in high resolution up to 720dpi.The first choice for common customers newly to printing industry.
Printing speed above is based on 16pcs of xaar128 printhead and 180*180dpi.

Configuration below is according to different models:
Motor: Japanese Panasonic, Fuji AC servo motor;
Rail:Japanese THK,Tawinese HWIN;
Heating system:front&back double heating;
Feed-in&take-up system:IR controlled auto feed-in&take-up system;
Printhead cleaning system: positive pressure, vaccum
Ink system:German KNF ink supply system,Japanese negative pressure system.

WARRANTY:We promise that we can guarantee to keep the whole printer in
good repair for one year,and no charge for repairing and adjusting,but
cunstomer should pay the airplane ticket,room and food for our
technician.




LIAONING ZHONGYE (ZY) TECHNOLOGY AND INDUSTRY DEVELOPMENT CO., LTD.







Contact person: eric lee      Skype:    eric.lee1103           MSN: eric-zhongyetech at
