Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > ZY-SK3400 Outdoor Digital Large Format Solvent Printer

ZY-SK3400 Outdoor Digital Large Format Solvent Printer

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Liaoning, China

Model Number:

ZY-SK3400

Contact Supplier Request Quote Chat Now

Liaoning Zhongye Technology And Industry Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Liaoning, China

Model Number ZY-SK3400

Specifications

printer Seiko SPT printhead,Fuji servo motor and THK rail,outdoor printing,1440dpi high resolution, 90m/h high speed,heavy model

Name	ZY-SK3400 printer
Class	ZY-SK series
Print technology	Drop-on-demand Piezo electric
Printhead	4pcs(4colors)/6pcs(6colors)(spt510/255)
Print width	3.2M
Resolution	1440dpi max
Speed	2pass 56m/h;4pass 36m/h;6pass 24m/h
Locating mode	Raster /servo
Color	CMYK LC LM
Media width	3.2M
Media handl	Roll to roll
Media types	Vinyl sheet and carpet paper,flex banner pvc mesh fabrics
Ink	Solvent/two-year outdoor life
File format	TIFF,JPEG,Postscript 3,EPS,PDF
Working process	Printmon software for windows xp
Rip	Photoprint /maintop
Power supply	50hz/60hz220v(10%)20A
Operation environmeng	(Tempperature )18-26(Humidity )40%-70%
Dimesion	5.2m1.4m1.5m
Weight	1500Kg

This model is with one group heads(one head each color), If require higher speed, you can choose our printer models with two groups heads(two heads each color, 8pcs heads for 4color and 12pcs heads for 6color).

1.Whole steel made drop-on-demand print head, super long life time,255 or 510 nozzles each head.

2.Color range reach up to 6 colors,720 to 144dpi in resolution, super choice for true-color, speed and resolution.

3.Voltage of heads is adjustable to the environment temperature, thus solve the problem of printing fading out of ink which is caused by temperature change

4.Powerful Maintop and Photoprint output software make easy operation, available for printing in two modes

5.Automatically skip the white area of printing, make higher effective

6.Need black only to print black words, no need 3 color or more color combination to make this print

7.Continue-printing system enable printing continue from where the power break-off, enable no waste time in break off period.

8.Aluminum beam for printing, lower noise, enable printing quietly.

9.Allow you to change the parameter of step double direction ,and speed while printing

10.Air sucking system on printing platform enable no scratching of heads and no draping over of media while printing. This make the higher resolution printing realized

11.Ink supply method: Automatic sensor for ink level, consistent ink supply by ink pump, also manual ink supply available

12. Automatic media rolling up and down system

13. Automatic print heads cleaning system, positive pressure cleaning and flushing cleaning available

14. Pre-heating, after-heating system equipped

15. Data transfer port: USB

16. Fuji motor and THK guide rail; Height adjustable heads carriage; automatical heads carriage cover.
Sending with the printer freely: One free spare parts kit; Software CD and Demo CD and manual;Free ink(1liter/color) and free cleaning solution; Sucker

Strong after sale service and warranty!

More different sizes and models available

Have got CE certificate

Contact Person: Rose Zhou

Mobile: 0086 13478324856
