Zhongye UVE Series(UV Economical Series) printers: adopting Epson DX5 print heads, UV LED drying system, steel belt DC driver, (alternative option: Guide rail, AC servo driver), working with UV ink, widely used for KT board, Paper board, PVC board, PS board, glass, ceramic, metal board, etc. all flate boards and roll-to-roll printing materials. Do you hope to have a printer with UV printer's functions but with an economical price? Now your price is realized. Our UVE series printers will be your best choice!
Features:
1. UV technology.
2. Economical price and ingenious design.
3. UV LED drying system, best and fast drying and curing. Even materials which cannot bear high temperature can also be printed very well.
4. With both roll-ro-roll and sheet-to-sheet media handling system, it is a real multifunctional UV printing equipment.
5. No need negative-pressure system, easier operation.
6. High resolution.
|
EFB1800 |
Print technology |
micro piezo dot-on-demand |
Print head |
1 group Epson DX5 printheads(paratactic structure)(2groups optional) 4color: CMYK/Servo |
Print width |
1.8m |
Height adjustable range |
2-5mm |
Resolution |
1440dpi max |
Speed |
Draft Model: 540*720dpi 28sq.m./h Production model: 720*720dpi 16sq. m. /h High quality model: 720*1440dpi 9sq. m./h |
Locating mode |
servo |
Color |
CMYK |
Media width |
1.8m |
Media handle |
Roll to roll sheet to sheet |
Media types |
Adhesive Vinyl, PVC, Mesh, Textile, Banner, Eco solvent inkjet paper etc. |
Heating system |
Front, back heating system(middle heating system is optional), middle flatbed sucker system, PID temperature controller |
Drying system |
outer fan |
Adjustable range |
room temperature-80°C |
Media handling system |
Auto media feeding, manual media releasing, Built-in variable adsorption |
Inks |
Eco-solvent Inks |
Ink Cartridge |
350ml, 8pieces |
File format |
TiFF, JPEG, |
Working system |
Windows XP |
Driver |
Professional bi-language software(Chinese&English) |
Rip |
Photoprint/maintop |
Power supply |
AC 50hz/60hz 220v-240v |
Operation enviroment |
1000W(max. power) 300W(normal working power) (Temperature)20-25(Humidity)40%-70% non condensation |
Demension |
2.84m*0.9m*1.25m |
Weight |
160kg |
