F8 Compact Filter

Specifications

Applied to large air flow ventilation system, filtration system of pharmaceutical, food, hospitals, clean room etc.

Goods description:



Common Applications: Applied to large air flow ventilation system, filtration system of Pharmaceutical, food, hospitals, clean room etc. It can be used as terminal-filtration of medium and high efficiency filtration system or pre-filtration of super-efficient filtration system.



Features: It is a kind of deep loading high efficiency filter, suitable for permanent or impermanent airflow system. It’s constructed to V-type by multiple mini-pleat media, installed in galvanized box or ABS plastic box. Compared with the common filters, it ideally enlarges the filter area, ensuring low media damage and low energy consumption to save cost in the present installation system.



Type	Dimensions W*H*D (mm)	Filter Area (m2)	Structure	Initial resistance & airflow (Pa & m3/h)
				F8
SHW-HV	287*592*292	8.4	Flanged Type 4V	68&1200
				90&1600
	592*592*292	18.8		68&2400
				90&3200
	305*610*292	13.5	Box Type 5V	68&1350
				90&1800
	610*610*292	27		68&2700
				90&3600



Compact Filter

Company

Workshop
