mini-pleat HEPA v-shape filter H13

Specifications

1.terminal-filtration of medium and high efficiency filtration system 2.low energy consumption;
3.large filter area

Speciality:





Common Applications: Applied to large air flow ventilation system, filtration system of Pharmaceutical, food, hospitals, clean room etc.

It can be used as terminal-filtration of medium and high efficiency filtration system or pre-filtration of super-efficient filtration system.



Features: It is a kind of deep loading high efficiency filter, suitable for permanent or impermanent airflow system. It’s constructed to V-type by multiple mini-pleat media, installed in galvanized box or ABS plastic box.



Compared with the common filters, it ideally enlarges the filter area, ensuring low media damage and low energy consumption to save cost in the present installation system.



 (specification):

Type	Dimensions W*H*D (mm)	Filter Area (m2)	Structure	Initial resistance & airflow (Pa&m3/h)
				F8	H10	H13
SHW-HV	287*592*292	8.4	Flanged Type 4V	68&1200	135&1200	180&1200
				90&1600	180&1600	240&1600
	592*592*292	18.8		68&2400	135&2400	180&2400
				90&3200	180&3200	240&3200
	305*610*292	13.5	Box Type 5V	68&1350	135&1350	180&1350
				90&1800	180&1800	240&1800
	610*610*292	27		68&2700	135&2700	180&2700
				90&3600	180&3600	240&3600
