Help CenterH13 Rectangular Filter
Related Products
Specifications
It's made of micro-fiberglass, used for filtering 0.3um dust particles.Goods description:
Common Applications: Filtering 0.3 microns or less suspended particles in the air, it is widely used in the terminal filtration of the civil or industrial cleaner places requiring a higher degree of cleanliness such as electronics, semiconductor, precision machinery, pharmaceuticals, hospitals, food etc.
Features: Adopting the superfine fiberglass filter paper as the media, separated by hot melt adhesive and fiberglass thread, sealed by the new polyurethane sealant, aluminum alloy frame with combined spray protection network both in the outlet and inlet side to protect filter paper. Low loss, high efficiency, light weight, it is tested precisely one by one.
Frame: Aluminum
Temperature resistance: 80 °C
Type |
Dimensions W*H*D (mm) |
Filter Area (m2) |
Resistance at the speed of 0.45m/s |
Recommended Airflow (m3/h) |
H14 | ||||
SHW-HW |
610*610*50 |
7.0 |
160 |
600-1000 |
305*305*70 |
2.5 |
135 |
100-250 |
|
305*610*70 |
5.0 |
135 |
300-500 |
|
610*610*70 |
10.2 |
135 |
600-1000 |
|
915*610*70 |
15.4 |
135 |
900-1500 |
|
305*610*90 |
6.5 |
100 |
300-500 |
|
610*610*90 |
13.1 |
100 |
600-1000 |
|
915*610*90 |
19.7 |
100 |
900-1500 |
|
1220*610*90 |
26.5 |
100 |
1200-2000 |
1,The wind speed of unidirectional flow clean system is generally less than 0.45m / s and the inlet side is 0.45m / s (90fpm) according to the test standard;
2, The resistance and air flow of the Close-pleat high efficiency filter are approximately proportional relationship.
3, “Recommended airflow” is only for non-unidirectional flow clean systems, such as dilution systems (also known as turbulent flow clean room)
|
European Specification CEN EN 1822 |
MPPS Efficiency |
Any point scan Local eff. |
Ep.0.3mm eff. |
Correspond to American Standard |
H13 |
≥99.95% |
≥99.75% |
≥99.99% |
MERV18 |
H14 |
≥99.995% |
≥99.975% |
≥99.999% |
MERV19 |
H15 |
≥99.9995% |
≥99.9975% |
≥99.9999% |
MERV20 |
H15 |
≥99.99995% |
≥99.99975% |
≥99.99999% |
MERV20 |
H13 Rectangular Filter
