H14 Mini-pleat HEPA Filter for food clean room

Specifications

1.used in the teminal filter.
2.Large filtering surface,
3.long working life,
4.large airflow,
5.easy installation



 Detailed Product Description

Common Applications:

Filtering 0.3 microns or less suspended particles in the air, it is widely used in the terminal filtration of the civil or industrial cleaner places requiring a higher degree of cleanliness such as electronics, semiconductor, precision machinery, pharmaceuticals, hospitals, food etc.



Features: Adopting the superfine fiberglass filter paper as the media, separated by hot melt adhesive and fiberglass thread, sealed by the new polyurethane sealant, aluminum alloy frame with combined spray protection network both in the outlet and inlet side to protect filter paper.



Low loss, high efficiency, light weight, it is tested precisely one by one.

Frame: Aluminum

Temperature resistance: 80 °C





Type	Dimensions W*H*D (mm)	Filter Area (m2)	Resistance at the speed of 0.45m/s			Recommended Airflow (m3/h)
			H13	H14	H15
SHW-HW	610*610*50	7.0	145	160	180	600-1000
	305*305*70	2.5	120	135	160	100-250
	305*610*70	5.0	120	135	160	300-500
	610*610*70	10.2	120	135	160	600-1000
	915*610*70	15.4	120	135	160	900-1500
	305*610*90	6.5	85	100	120	300-500
	610*610*90	13.1	85	100	120	600-1000
	915*610*90	19.7	85	100	120	900-1500
	1220*610*90
