Product Details:
| Standard or Nonstandard | Standard |
|---|---|
| Structure | Control |
| Pressure | Medium Pressure |
| Power | Electromotion |
| Material | Alloy |
| Temperature of Media | Medium Temperature |
| Port Size | 300Nm/800Nm/1000Nm |
| Place of Origin | Zhejiang, China (Mainland) |
| Model Number | HL-100 |
| Brand Name | HELI |
1. Detailed information
Model
| HL-100 | HL-200 | ||||||||||||||
Power | AC24V | AC110V | AC220V | AC380V | AC24V | AC110V | AC220V | A380V | ||||||||
Motor power | 100W | 100W | ||||||||||||||
Rated current | 9A | 2.2A | 1A | 0.48A | 9A | 2.2A | 1.2A | 0.48A | ||||||||
Output torque | 300Nm/800Nm/1000Nm | 1000NM | 200Nm | 2000Nm | ||||||||||||
Action time | 15S/30S/50S | 30S | 100S | 50S | ||||||||||||
Circuit control | B,S,R,H,A,K,D,T | |||||||||||||||
Rotary angle | 0-90° | |||||||||||||||
Weight | 11.2Kg | 11.8 Kg | ||||||||||||||
Voltage-with standing value | 1500VAC/1min | |||||||||||||||
Insulated resistance | 100MΩ/500VDC | |||||||||||||||
Protection class | IP67 | |||||||||||||||
Surrounding Temperature | -25°C~60°C(The other temperature can be customized) | |||||||||||||||
Installation angle | Any angle | |||||||||||||||
Case material | Aluminium die-casting components | |||||||||||||||
Optional function | Overload protection, heater | |||||||||||||||
2. Packing
2PCS/43.5*32.5*25/CTN 24KGS/CTN
3. Delivery time
refer to quantity and production department plan
4.Payment Terms
We do payment in L/C at sight
But always is in T/T,30% deposit and 70% balance before shipment.
5.Supply Ability
500 Set/Sets per Week 2,000pcs/month
6. Sample:
We may need 7 days to make the sample with 1 pc ,
also we need the sample fee and the express fee,but there would be return after place order.
7. MOQ: 1pcs
