Help CenterG120C Small Diesel Engine
Related Products
Specifications
Type: small diesel engineRated output:7.72(10.5)kw(HP)
Rated speed:2400r/min
NO. |
ITEMS |
UNIT |
MODEL |
G120C | |||
1 |
Type |
|
Single cylinder, horizontal, water-cooled, 4-cycle |
2 |
Bore×stroke |
mm×mm |
94×90 |
3 |
Displacement |
mL |
625 |
4 |
Rated speed |
r/min |
2400 |
5 |
Continuous rated output |
Hp |
10.5 |
6 |
Max. output |
Hp |
12 |
7 |
Idle speed |
r/min |
≤600 |
8 |
Compression ratio |
|
21:1 |
9 |
Cooling system |
|
Radiator |
10 |
Combustion system |
|
(TVCS) Three vortex combustion system |
11 |
Fuel delivery position |
|
19°~21° |
12 |
Fuel injection pressure |
kgf/cm2 |
120~125 |
13 |
Lubricating system |
|
Forced lubrication with trochoid pump |
14 |
Starting system |
|
Electric startup,Speed doubling handle hand |
15 |
Direction of rotation |
|
Counter clockwise facing flywheel |
16 |
Cooling water capacity |
L |
2.1(Radiator) |
17 |
Fuel tank capacity |
L |
10 |
18 |
Crankcase oil capacity |
L |
2.3 |
19 |
Measurement |
mm |
765×350×520 |
20 |
Net weight |
kg |
117 |
Usage Agriculture
Fuel Diesel
Stroke 4 Stroke
Cylinder Single Cylinder
Cold Style Water-cooled
Start Electric Start
