PC-TSD Wall Mount Servo Control AC Automatic Voltage Regulator / Voltage Stabilizer 110V/220V 50HZ/60HZ
| Model | PC-TSD3500VA | PC-TSD5500VA | PC-TSD8000VA | PC-TSD10000VA | ||||
| Technology | Servo Motor control+Micro compute programed control | |||||||
| LCD Display LED Display | Color | Red/Green/White/blue | ||||||
| Info | Input Voltage/Output Voltage/Load Usage/Time Delay/Normal Working/Protection | |||||||
| Protection | Over Voltage | Output voltage ≥248v±4 | ||||||
| Low Voltage | Output voltage ≤170V±4 | |||||||
| Over Loading | more than 120% | |||||||
| Over Temperture | 120±10 | |||||||
| Delay time | Long time(255 second)/short time (5 second) | |||||||
| Circuit breaker | Regulator /By-Pass | |||||||
| Language | English/Russian/Chinese | |||||||
| Input Voltage | AC150-270V | |||||||
| Output Voltage | 220V±3% ; adjustable | |||||||
| Frequency | 50Hz/60Hz | |||||||
| Phase | Single Phase | |||||||
| Efficiency | ≥90% | |||||||
| Ambient Temperature | –15~45 | |||||||
| Relative Humidity | <95% | |||||||
| Waveform distortion | no additional wave form distortion | |||||||
| Insulating Resistance | Normally more than 2MΩ | |||||||
| Specifications | ||||||||
| Power | 3500W | 5500W | 8000W | 10000W | ||||
| Packing Size | 43.5x30.5x39cm | 46.5x34x43.5cm | 46.5x34x43.5cm | 51.8x38.8x27cm | ||||
| Packing | 2 | 2 | 2 | 1 | ||||
| G.M | 28 | 36 | 45 | 29 | ||||
Service for sample:
We can provide sample for your testing
After-sale service:
Policy:1.sent the spareparts
2.sent you the documents of technical skills for repairing the cargo
we will sent the sparepartsfor example,LED display,PCB,carbon brush in case of demage.It will be sent together with the cargos.
Warranty 2 year
100% Enough Power
Now many factory produce less than 100% power stabilizer,or printing 10kva at outside face panel, but actually only 8kva power.We promise just provide 100% enough power voltage stabilizer,never use this way to cheat customers, the sincerest factory bring you the best products.
Certification: CE/ISO9001/SON CAP/ISO14001/SGS/CQC
Q1. What’s the payment term?
A. We accept TT, 30% deposit and 70% balance against copy of BL.
Q2. How’s the delivery time?
A. About 10-25 days for production.
Q3. Tell me the standard of package?
A. For the small capacity, color box as inner package and carton as delivery package. For big capacity, use strong wooden case for protection.
Q4. What kind of material of transformer?
A. Two types: 100% copper, copper with aluminum. Copper is better and also higher price.
Q5. How about the logo? OEM will be ok?
A. Our logo is TTN. If you place big order, we can accept your logo. So OEM is ok. But you use our logo TTN will be high appreciated.
1)We are professional manufacturer of Voltage Stabilizer/Car power inverter/UPS/Solar control system founded in 1994 year with 33,000 square meter building.
2)We have own Research/Development Department,one of our technician have more than 20years experience produce voltage stabilizer .
3) We have strictly Test systems and equipment of PCBA/transformer/finished product,check each step,each article goes through a strategic pass,lets the users be satisfied.
4 ) As manufacturer we have 12product lines, daily output 2500pcs. We can expedite for you every day, guarantee not delay your delivery time.
5 )Best OEM/ODM service.
