Can Filling Canning Line / juice canning machine
general description
1). Compact structured, good-looking, easy to operate and highly automated.
2). Air conveyor is directly linked with feed-in starwheels, making it easier to change bottles without screws and conveyor chains.
3). Bottles are transferred in the manner of clamping neck. Bottles can be changed through some replacement of steel clamps, which instead of adjusting the height of machine.
4). Rinser-clamp which special design is strong and endurable, no contact with bottle-mouth, to prevent pollution.
5). Highly effective spraying nozzles equipped on the rinser-clamp can rinse every side of inner bottle and save water.
6). Accessories which contact with material are all made of stainless steel, no dead angles and easy to clean up.
7). Replacement between CO2 and O2 ensure almost no O2 in bottle, long filling pipe reduce O2 content to null.
8). Valve on-off system is driven by hydraulic cylinder, which starts on bottle signals.
9). High-speed and highly accurate bottling valves ensure no loss of liquid at high speed.
10). Equipped with CIP clean-in-place.
11). Bottom splint which fixed in the feed-out starwheel goes down in the manner of screw. Bottles can be changed without adjustment of height of conveyor chain.
12). Capping heads are magnetic constant-torque equipped to ensure capping quality with no damage.
13). Highly effective cap sorting and feed in system is protective for feed in and cap absence.
14). Equipped with overload system to safeguard machine and operators.
15). Touch screen operated.
16). Main electronic components( touch screen, PLC and frequency inverter) are imported products.
Technical Data
Model |
SG12-4 |
SG18-4 |
SG20-4 |
SG30-6 |
The number of capping head |
4 |
4 |
4 |
6 |
The number of filling head |
12 |
18 |
20 |
30 |
Production capacity(cans/min) |
150 |
250 |
150 |
250 |
Can Diameter(mm) |
52.5-99 |
52.5-99 |
52.5-99 |
52.5-99 |
Can Height(mm) |
39-160 |
39-160 |
80-160 |
80-160 |
Power(kw) |
5.5 |
5.5 |
5.5 |
7.5 |
Weight(kg) |
3100 |
3800 |
4000 |
6000 |
Dimension(mm) |
2700*1400*1900 |
3050*1750*1900 |
3400*1950*1900 |
3900*2400*1900 |
images for your reference
washing part
filling part
capping part
The sample service
1.we can send you the video of the running machine
2.you are welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city.
3.If we get the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.
Customized service
1.we can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on).
2.we will give you our professional suggestion,as you know,we have been in this industry for many years.
After-sales service
1.we will provide the bill of load on time to make sure you can get the machine quickly
2.when you finish the Preparation conditions ,our engineer will go to your factory to install the machine ,and give you the operating manual ,and train your employee until they can operate the machine well.
3.we provide one year warranty with spare parts free.
Export market
WHY CHOOSE SHEENSTAR
1. concentrated on various filling machines for many years
2. competitive price with high quality
3. installation and debugging service
4.location is near to ShangHai
5. one year warranty
6.We keep pursuing high quality, fast delivery and sincere service.
sheenstar will be your best choice
(for more information,please contact us)
sincere service for you
