12W Round IP44 LED Downlight With Lifespan 50000H
US$ 3 - 18
MOQ: 10 Pieces
Key Specifications
Get Latest Price
LED Light Source:
SMD2835
Warranty(Years):
3
Input Voltage(V):
AC85-265V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Best Quality LED Downlight 5W From YunboUS$ 3 - 18MOQ: 10 Pieces -
High Quality CE Approved LED DownlightUS$ 3 - 18MOQ: 10 Pieces
-
Most Popular 7W Dimmable LED DownlightUS$ 3 - 18MOQ: 10 Pieces
-
Hot Sale IP44 Downlight LED From China SupplierUS$ 3 - 18MOQ: 10 Pieces
-
Voltage 230V 18W LED Downlight From ChinaUS$ 3 - 18MOQ: 10 Pieces
LED Light Source
SMD2835
Warranty(Years)
3
Input Voltage(V)
AC85-265V
Lamp Power(W)
12
Lamp Luminous Flux(lm)
900
Lamp Luminous Efficiency(lm/w)
100
Color Temperature(CCT)
Cool White
Working Temperature(℃)
-25, 55
Working Lifetime(Hour)
35000
Lamp Body Material
Aluminum
IP Rating
IP44
Certification
CE, EMC, LVD
Model Number
YB-TD05-15
Place of Origin
Jiangsu, China
Brand Name
Yunbo
Specifications
12W Round IP44 LED Downlight With lifespan 50000H1.High quality SMD 2835
2 power factor up to 0.9
3.No flicker,energy saving
12W Round IP44 LED Downlight With lifespan 50000H
Products Feature:
Led driver:constant current output and safety isolating.Two years warranty
Led components SMD5630 is packaged by one of professional factory in Shezhen.
High quality diffuser plate make light even.
Heat dissiapation body adopt ADC12 Al and Al is over 82%;better heat dissipation capability
Specification:
Item |
Symbol | 2.5inches Down Light | 4inches Down Light | 5.5inches Down Light | 8inches Down Light | |||
| Model No. | / | YB-TD2.5-03 | YB-TD04-07 | YB-TD04-09 | YB-TD5.5-15 | YB-TD5.5-18 | YB-TD08-24 | YB-TD08-32 |
| Rated Power | W | 3W | 7W | 9W | 15W | 18W | 24W | 32W |
| Luminous Flux | LM | 220Lm | 580Lm | 725Lm | 900Lm | 1300Lm | 1800Lm | 2300Lm |
| Product Dimension | mm | Φ90*H55 | Φ130*H62 | Φ180*H70 | Φ230*H86 | |||
| Cut-out | mm | Φ77 | Φ113 | Φ163 | Φ205 | |||
| Power Factor | PF | PF>0.9 | ||||||
| Input Voltage | V | AC85-265V | ||||||
| Color Temperature | TC (K) | WW:2500-4000K, NW:4000-5000K PW:5000-6000K CW: >6000K | ||||||
| Color Index(Ra) | Ra | Ra>70 OR Ra >80 | ||||||
| Life Time | Hours | 3 years | ||||||
| Operating Temperature | °C |
-25°C~+55°C |
||||||
Applications:
well suited for commercial and residential application,
For instance:bathroom, boats,villa,restaurant,hotel,hall,meeting,room,office,living room,
exhibition room, gallery, museum, reading room, bar, bathroom, school, bedroom, buildings, underground parking garage, supermarket, shopping mall etc.
