Sanlong technology centrifugal concrete pipe mold

1) Concrete Pipe Diameter: 100-2000mm

2) Concrete Pipe length: 1000-8000mm

3) Pipe Joint: Flush joint , Bell&Spigot Joint, Collar Joint

4) Pipe Standards: European Standards or ASTM Standard

First, This is the earliest technology to make reinforced concrete pipes, with centrifugal force generated by high speed rotation of the round pipe mold to make concrete compressed and solid . During the production, Distrubute concrete by concrete pipe feeding machine, and please notice to use a long stick long as the mould, to ensure that the concrete is distributing evenly around the mould.
Secondly, after finish feeding concrete usually will let the mould running at a higher speed for 3-5 mins, when seeing the inner wall looks smooth, then stop the machine. we can use gantry crane to lift up the mould to the curing tank, after steam curing for at least 3-5 hours, the mould can be taken off. then the pipe is done, if find the pipe with some little defect, workers can repair it with some concrete.
At last, the pipes is curing by normal temperature for several hours, they can be used for culverts, drainage, bridge ...and the mould can be used for the next cycle of production.
